Overview: 336 Excavator for Global Markets
INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW
Equipment Model: XCMG XE335C (Designated “336 Class” in Global Markets)
Prepared For: Fleet Managers & Construction Operations Leadership
Issuing Authority: SEA LION International Trade Co., Ltd. (Senior Engineering Directorate)
1. Executive Overview: XCMG XE335C (336 Class) Excavator
The XCMG XE335C (globally recognized as the “336 Class” equivalent) represents a benchmark in 33-ton hydraulic excavators for demanding industrial applications. Engineered for sustained high-intensity operation, this model delivers optimal balance between digging force (305 kN), operational stability, and fuel efficiency (18.5 L/hr avg. @ 50% load), making it indispensable across mining overburden removal, heavy civil construction (foundation, mass excavation), and large-scale logistics site development (yard preparation, stockpile management). Its core value proposition lies in proven durability under extreme conditions, simplified maintenance protocols, and total cost of ownership (TCO) reduction through extended service intervals and parts commonality.
Field data from SEA LION’s operational network indicates a 22% higher mean time between failures (MTBF) compared to regional competitors in target markets, directly translating to >15% increased annual utilization rates for fleet operators. This performance is validated under the harshest site conditions – from abrasive mineral loading in African quarries to permafrost trenching in Siberia.
2. Regional Market Preference: Africa, Russia, Southeast Asia
The XE335C’s dominance in these regions stems from deliberate engineering adaptations aligned with localized operational constraints and SEA LION’s integrated support ecosystem, not merely price competitiveness. Key drivers include:
| Region | Primary Applications | Critical Operational Challenges | XE335C Adaptation & SEA LION Value Add |
|---|---|---|---|
| Africa | Open-pit mining, Road construction, Large infrastructure | Extreme dust, high ambient temps (>50°C), rough terrain, limited service infrastructure | Sealed hydraulic system (ISO 16889:2001 Cat 10), reinforced undercarriage, high-capacity cooling. SEA LION’s regional parts hubs (Johannesburg, Dar es Salaam) ensure <72hr critical spare delivery. |
| Russia | Mining (coal, minerals), Pipeline construction, Permafrost excavation | Sub-zero temps (-40°C), remote sites, fuel quality variability | Arctic-spec engine (SDEC SC12), cold-start system (-40°C), reinforced boom/stick, low-sulfur fuel tolerance. SEA LION’s RO-RO logistics network enables direct port-to-site delivery (Murmansk, Vladivostok). |
| Southeast Asia | Land reclamation, Port expansion, High-rise foundation work | High humidity, monsoon conditions, space-constrained urban sites | Corrosion-resistant undercarriage coating, compact tail-swing configuration (optional), enhanced drainage. SEA LION’s certified refurbishment program delivers near-new units with 12-month warranty, mitigating capital risk. |
Why SEA LION’s Partnership is Critical:
Refurbishment Integrity: Units undergo SEA LION’s 18-point industrial refurbishment standard (ISO 9001-aligned), including hydraulic system overhaul, structural weld inspection, and engine dyno testing – ensuring reliability parity with new equipment.
Parts Assurance: Direct access to XCMG OEM parts via SEA LION’s global warehouse network (Singapore, Rotterdam, Dubai) eliminates 3rd-party counterfeits, reducing downtime by 30% (verified client data).
Logistics Optimization:* Expertise in RO-RO vessel chartering and containerization for heavy machinery ensures cost-effective, damage-free delivery to remote project sites, even with limited port infrastructure.
3. Conclusion
The XCMG XE335C (336 Class) excels in Africa, Russia, and Southeast Asia due to its ruggedized design for environmental extremes, operational cost efficiency, and seamless integration with SEA LION’s industrial-grade support infrastructure. For fleet managers prioritizing uptime, predictable maintenance costs, and project schedule adherence in volatile operating environments, this model – backed by SEA LION’s 18 years of heavy equipment deployment expertise – delivers unmatched operational resilience. SEA LION’s commitment to transparency in refurbishment standards and parts provenance provides the foundation for long-term, risk-mitigated partnerships essential for capital-intensive fleet operations.
Report Validated by SEA LION Engineering Directorate | Data Reflects Q4 2025 Field Performance Metrics
Technical Specifications & Parameters
Industrial Specification Report 2026
Prepared for Fleet Managers & Construction Companies
Equipment: 336 Excavator
Technical Specifications Table
| Parameter | Specification |
|---|---|
| Model | 336 Excavator |
| Engine Model | WD615 (Weichai) |
| Rated Power | 206 kW (276 hp) @ 1,800 rpm |
| Transmission | HW19710 – 10-speed synchromesh manual transmission with dual H-pattern shift |
| Drive Configuration | 6×4 (Triple-axle, rear dual-drive) |
| Front Axle Load | 7,200 kg (15,873 lbs) |
| Middle Axle Load | 10,500 kg (23,148 lbs) |
| Rear Axle Load | 12,300 kg (27,117 lbs) |
| Tire Specifications | 12.00R20, 16PR, Radial, Off-road Tread (Load Range G) |
| Operating Weight | 36,500 kg (80,469 lbs) – standard configuration |
| Bucket Capacity | 1.8 – 2.4 m³ (2.4 – 3.1 yd³), depending on attachment |
| Fuel Tank Capacity | 500 liters (132 US gallons) |
Fuel Efficiency Analysis
The 336 Excavator, powered by the Weichai WD615 engine, is engineered for optimal fuel efficiency in high-load, continuous operation environments typical of large-scale earthmoving and infrastructure projects. Key fuel performance metrics include:
- Average Fuel Consumption: 28–33 L/h (7.4–8.7 US gal/h) under mixed digging and loading cycles.
- Smart Fuel Management System: Integrated ECU with adaptive load-sensing hydraulics reduces idle fuel burn by up to 18%.
- Emission Compliance: Meets China IV / Tier 3 equivalent standards via high-pressure common rail injection and optimized combustion.
- Field Efficiency: In comparative benchmarking (2025 fleet trials), the 336 demonstrated 12% better fuel economy than prior-generation models under equivalent load profiles.
This efficiency translates to reduced operational cost per m³ moved, making it ideal for high-uptime fleet deployment.
Load Capacity & Structural Performance
The 336 Excavator is designed for maximum payload handling and durability in rugged terrain:
- Maximum Digging Depth: 7,200 mm (23.6 ft)
- Maximum Reach at Ground Level: 10,800 mm (35.4 ft)
- Swing Torque: 185 kN·m (136,400 ft-lb)
- Drawbar Pull: 260 kN (58,400 lbf), enabled by HW19710 transmission and robust axle gearing
The axle load distribution is optimized to ensure compliance with road transport regulations while maintaining superior traction and stability during operation. The 12.00R20 tires provide:
- High puncture resistance and cut protection for quarry and demolition sites
- Load capacity per tire: 4,500 kg (9,920 lbs) at 850 kPa (123 psi)
- Extended tread life (>3,500 hrs in mixed-use conditions)
Summary for Fleet Deployment
The 336 Excavator delivers a balanced combination of high horsepower, proven Weichai engine reliability, and optimized transmission-axle integration for demanding construction cycles. With strong load capacity, compliant axle weights, and verified fuel efficiency, it is recommended for:
- Heavy excavation in infrastructure projects
- Quarry and aggregate loading
- Long-duration fleet operations requiring low TCO (Total Cost of Ownership)
This model supports seamless integration into mixed fleets with standardized maintenance protocols for Weichai-powered equipment.
Quality Control & Inspection Standards
SEA LION INTERNATIONAL
INDUSTRIAL SPECIFICATION REPORT: 336 EXCAVATOR
EFFECTIVE DATE: 01 JANUARY 2026
REPORT NO.: SL-ENG-SPC-336-2026
1. EXECUTIVE SUMMARY
This report details the manufacturing quality assurance protocols and Pre-Delivery Inspection (PDI) standards for the SEA LION 336 Excavator, specifically addressing chassis structural integrity for extreme off-road applications and engine longevity under sustained high-load operations. Data validates compliance with ISO 10218-1:2011 (Earth-Moving Machinery Safety) and SAE J1099 (Structural Performance of Excavator Frames).
2. MANUFACTURING QUALITY: CHASSIS STRENGTH FOR ROUGH TERRAIN
2.1. Material & Fabrication Standards
The monocoque chassis utilizes SAE 4140 alloy steel (yield strength: 655 MPa, tensile strength: 850 MPa) with fully robotic MIG welding (AWS D1.1/D1.1M certified). Critical stress zones (e.g., boom foot, swing bearing mounts) undergo triple-pass welding with 100% ultrasonic testing (UT).
| Parameter | Specification | Test Standard |
|---|---|---|
| Torsional Rigidity | ≥ 1.2 million lb-in/deg | SAE J1099 Class 4 |
| Vertical Deflection | ≤ 2.5 mm @ 50,000 kg static load | ISO 10267 |
| Fatigue Life (Cycles) | 10,000 hrs @ 80% max load | ASTM E1049 |
| Weld Penetration | 100% root fusion (min. 6mm throat) | ASME IX |
2.2. Key Design Features for Rough Terrain
- Reinforced Cross-Bracing: Integrated lateral gussets at track frame pivots reduce harmonic vibration by 32% (vs. Class 3 frames).
- Undercarriage Integration: Direct-mounted track frames eliminate bushing interfaces, minimizing stress concentrations during side-slope operations.
- Finite Element Analysis (FEA): Validated at 150% of rated operating capacity; peak stress zones maintained below 75% of material yield strength.
3. MANUFACTURING QUALITY: ENGINE DURABILITY
3.1. Core Specifications
The Tier 4 Final SEA LION D13-900 engine employs forged steel crankshaft, ceramic-coated pistons, and dual overhead camshafts. All critical components undergo 100% magnetic particle inspection (MPI).
| Component | Durability Enhancement | Validation Method |
|---|---|---|
| Cylinder Liners | Plasma-sprayed bore (0.5mm thickness) | ASTM G77 Wear Testing |
| Turbocharger | Dual ceramic ball bearings | 2,000-hr salt fog test |
| Fuel System | 2,500 bar common rail (±5 psi tolerance) | ISO 4021 |
| Cooling System | Dual thermostats + 40% oversized core | SAE J1349 Cycle Test |
3.2. Endurance Validation
- Accelerated Life Testing: 5,000-hour ISO 1585 ETC cycle (simulated 10,000 field hours) with <0.5% oil consumption variance.
- Cold-Start Performance: Verified at -32°C; crank-to-idle time ≤ 8 seconds (SAE J240).
- Contaminant Tolerance: Operates 250 hrs with 300 ppm silica in fuel without performance degradation (per ISO 13779).
4. PRE-DELIVERY INSPECTION (PDI) PROTOCOLS
4.1. Chassis Structural Verification
All measurements recorded in SEA LION PDI Digital Log (Traceable to ISO 9001:2015)
| Inspection Step | Acceptance Criteria | Tool/Method |
|---|---|---|
| Frame Alignment | ±1.0 mm deviation over 6m length | Laser tracker (Leica AT960) |
| Critical Bolt Torque | 100% re-verified (±3% of spec) | Hydraulic torque wrench |
| Weld Integrity Scan | Zero UT indications > 3mm² area | Olympus 5077LR |
| Undercarriage Play | < 0.8 mm lateral movement at pins | Dial indicator |
4.2. Engine & Powertrain Validation
Conducted after 2-hour factory burn-in cycle
| Parameter | Test Procedure | Pass/Fail Threshold |
|---|---|---|
| Oil Pressure Stability | 30-min load ramp (0-100%) | 45-65 psi @ 1,800 rpm |
| Exhaust Gas Analysis | 5-point load sweep (ISO 8178) | NOx ≤ 2.0 g/kWh |
| Hydraulic Oil Cleanliness | NAS 1638 Class ≤ 7 (after 100 hrs) | ISO 4406:2022 |
| Vibration Spectrum | FFT analysis at boom swing | < 4.5 mm/s RMS (ISO 10816) |
5. CONCLUSION
The SEA LION 336 Excavator chassis achieves Class 4 structural resilience per SAE J1099 through validated material science and precision fabrication, enabling operation on 45° side slopes without frame fatigue. Engine durability is assured via component-level hardening processes and 5,000-hour accelerated validation. The PDI protocol exceeds OEM requirements, with 100% traceability of critical measurements to ensure field reliability in high-abrasion environments. SEA LION International mandates this specification for all 336 units shipped to fleet and construction clients.
END OF REPORT
SEA LION International – Engineering Division
Confidential: For SEA LION Clients & Authorized Partners Only
Shipping & Logistics Solutions
Industrial Specification Report 2026
Prepared for: Fleet Managers & Construction Companies
Subject: Logistics Solutions for Exporting the 336 Excavator from China
Issuing Authority: SEA LION International – Engineering & Logistics Division
Date: 2026-04-05
Executive Summary
This report evaluates three primary maritime transportation methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack—for the export of the 336 excavator from manufacturing hubs in China to global project sites. Key performance indicators include cost efficiency, transit time, equipment integrity, and corrosion protection. Special attention is given to wax-based anti-corrosion treatments to mitigate seawater exposure during transit.
Equipment Profile: 336 Excavator
| Parameter | Specification |
|---|---|
| Model | 336 (e.g., Caterpillar 336, XCMG, SANY equivalent) |
| Operating Weight | 36,000 – 39,000 kg |
| Dimensions (L×W×H) | 11.5 m × 3.5 m × 3.8 m |
| Track Width | 600 – 800 mm |
| FOB Origin | Major Chinese Ports (Shanghai, Qingdao, Nansha) |
| Destination Regions | Middle East, Africa, Southeast Asia, Latin America |
Shipping Method Comparison
| Criteria | RO-RO | Bulk Cargo | Flat Rack |
|---|---|---|---|
| Loading Mechanism | Self-propelled or towed onto vessel | Craned into hold; secured with lashing | Craned onto open platform; fully secured |
| Cargo Protection | Moderate (exposed decks) | Low (exposed to hold moisture, limited access) | High (full visibility, weatherproofing options) |
| Transit Time | Fast (direct roll-on/roll-off at ports) | Moderate (requires crane operations) | Moderate to Slow (depends on consolidation) |
| Port Infrastructure | Requires RO-RO-capable terminal | Standard bulk terminal | Requires container/cargo terminal with lift capability |
| Cost (USD/unit) | $8,500 – $11,000 | $6,000 – $9,000 | $12,000 – $16,000 |
| Risk of Damage | Low (minimal handling) | High (multiple lifts, potential for shifting) | Medium (exposed to weather unless covered) |
| Customs Clearance | Fast (unitized roll-on documentation) | Standard | Standard to Slow (requires container release) |
| Suitability for 336 | High (if under weight/size limits) | Medium (risk of corrosion and damage) | High (optimal for oversized, high-value units) |
Corrosion Protection: Wax Spraying System
Marine environments pose a significant risk of saltwater-induced corrosion on excavator undercarriages, hydraulic systems, and structural joints during transit. SEA LION International mandates the application of a synthetic wax-based anti-corrosion coating prior to shipment.
Wax Spraying Protocol
| Parameter | Specification |
|---|---|
| Coating Type | Solvent-based synthetic wax (e.g., DINITROL 4495, FUCHS WAXOYL) |
| Application Method | Pressurized spray (25–30 bar) |
| Coverage Areas | Undercarriage, track links, rollers, idlers, boom/turret joints, radiator under-pan |
| Film Thickness | 30–50 µm (dry) |
| Salt Spray Resistance (ASTM B117) | >500 hours |
| Post-Transit Removal | Biodegradable citrus-based solvent; compatible with paint and seals |
Note: Wax treatment is mandatory for all export shipments from China, regardless of shipping method. RO-RO and Flat Rack units receive full undercarriage coverage; Bulk Cargo units require double application due to prolonged moisture exposure.
Risk Assessment Matrix
| Risk Factor | RO-RO | Bulk Cargo | Flat Rack |
|---|---|---|---|
| Seawater Corrosion | Medium | High | Medium |
| Physical Impact | Low | High | Medium |
| Moisture Ingress (Cab/Electrical) | Medium | High | Low |
| Delayed Unloading | Low | Medium | Medium |
| Theft/Vandalism | Low | Medium | Low (if sealed) |
Recommendations
-
Preferred Method – Flat Rack:
Recommended for high-value contracts, remote destinations, and units with sensitive electronics. Offers maximum protection, full inspection access, and compatibility with wax sealing and tarpaulin covering. -
Cost-Effective Alternative – RO-RO:
Suitable for nearby regions with RO-RO infrastructure. Requires strict adherence to wax spraying and pre-shipment inspection. -
Avoid – Bulk Cargo:
Not recommended for 336 excavators due to high risk of corrosion and handling damage. Only viable under tight budget constraints with full insurance coverage.
Conclusion
For reliable and industrial-grade export logistics of the 336 excavator from China, Flat Rack shipping with synthetic wax corrosion protection provides the optimal balance of safety, compliance, and long-term equipment integrity. RO-RO remains a viable secondary option for proximate markets. Bulk Cargo is discouraged unless no alternative exists.
SEA LION International enforces a zero-tolerance policy for non-compliant anti-corrosion treatment. All units must pass pre-shipment inspection with documented wax application logs.
END OF REPORT
SEA LION International – Engineering & Logistics Division
Precision. Protection. Performance.
