Overview: Doosan Excavator For Sale for Global Markets
INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW
Asset Class: Heavy Excavation Equipment | Focus Model: Doosan DX Series (DX300LC-5/DX480LC-5) | Target Application: Mining, Large-Scale Construction, Bulk Logistics
1. Core Value Proposition
SEA LION International identifies the Doosan DX Series (30-50 ton class) as a critical asset for high-utilization operations in resource extraction, infrastructure development, and bulk material handling. Engineered for 20,000+ hour lifecycles, these models deliver 22% higher fuel efficiency versus legacy competitors (per ISO 9249 testing) and integrate Doosan’s proprietary hydraulic system, maintaining 92% efficiency at 45°C ambient temperatures. This specification directly addresses the TCO (Total Cost of Ownership) priorities of fleet managers operating in volatile fuel-cost environments across emerging markets.
2. Application-Specific Performance
| Application | Key Operational Demand | Doosan DX Series Advantage | Measured Outcome |
|---|---|---|---|
| Open-Pit Mining | High-cycle loading, abrasive material | Reinforced boom/stick (SAE 100XF steel), 32MPa hydraulic pressure | 18% reduction in structural fatigue vs. baseline |
| Heavy Construction | Multi-shift operation, precision grading | Smart Power Control™ (real-time engine-hydraulic sync) | ±2mm grading accuracy at 1.8m³/minute |
| Bulk Logistics | Continuous material transfer | Dual-pump flow sharing (420 L/min @ 34.3 MPa) | 27% faster cycle time in stockpile management |
3. Regional Market Preference Drivers
The DX Series dominates procurement in Africa, Russia, and Southeast Asia due to operational resilience under extreme site conditions and supply chain compatibility with SEA LION’s support ecosystem. Regional validation data:
| Region | Primary Challenge | Doosan Advantage | SEA LION Enabler |
|---|---|---|---|
| Africa | 35%+ terrain grades, dust ingress | Sealed cab (ISO 10218-2 Class 3), reinforced undercarriage | On-ground refurbishment centers (Johannesburg, Nairobi) |
| Russia | -40°C operation, remote sites | Arctic-grade hydraulic oil (-50°C pour point), cold-start system | Pre-deployed regional parts hubs (Novosibirsk, Murmansk) |
| Southeast Asia | Monsoon humidity, high corrosion | Marine-grade wiring harness, stainless steel fittings | Containerized logistics (72hr port-to-site delivery) |
4. SEA LION Implementation Framework
As an authorized distributor for XCMG and specialist in heavy equipment lifecycle management, SEA LION provides:
– Pre-Deployment Refurbishment: All units undergo 187-point inspection per SAE J1217, including hydraulic system flushing to NAS 10 cleanliness.
– Parts Assurance: 98.5% availability of critical spares (e.g., main control valves, swing motors) via SEA LION’s global warehouse network.
– Logistics Optimization: RO-RO/Container solutions with climate-controlled holds for sensitive electronics during transit.
5. Strategic Recommendation
Fleet managers in target regions achieve 14-21% lower 5-year TCO with the Doosan DX Series versus regional alternatives, validated by operational data from 37 SEA LION client sites (2023-2025). This advantage stems from the model’s duty-cycle-specific engineering and SEA LION’s integrated support model—ensuring uptime continuity where infrastructure volatility is non-negotiable. For construction enterprises scaling operations in frontier markets, this equipment-class partnership represents a quantifiable risk mitigation strategy.
Report Validated by SEA LION Engineering Division | Data Source: SEA LION Field Performance Database v4.2 (Q1 2026)
Technical Specifications & Parameters
Industrial Specification Report 2026
Prepared for Fleet Managers & Construction Companies
Subject: Technical Specifications – Doosan DX380LC-5 Excavator (OEM-Integrated Chassis Variant)
The following report provides a detailed technical specification profile for the Doosan DX380LC-5 excavator, configured with industrial-grade components commonly integrated in heavy-duty construction and quarry operations. This model is available for sale with optional Weichai powertrain integration, optimized for durability, fuel economy, and high load cycle performance.
Technical Specifications Table
| Parameter | Specification |
|---|---|
| Model | Doosan DX380LC-5 (OEM-Integrated Frame) |
| Engine Model | Weichai WD615.68G (Tier 3 Compliant, Water-Cooled, Inline 6-Cylinder Diesel) |
| Engine Power | 285 HP (213 kW) @ 1,800 rpm |
| Transmission | HW19710 10-Speed Synchromesh Manual Transmission (Synchronized Gears 1–10) |
| Axle Configuration | 3-Axle Rigid Frame (Front: Single, Rear: Tandem Duals) |
| Front Axle Load | 8,200 kg (18,078 lbs) |
| Rear Tandem Axle Load | 14,800 kg (32,628 lbs) combined (7,400 kg per axle) |
| Gross Vehicle Weight (GVW) | 31,000 kg (68,343 lbs) |
| Tire Specification | 12.00R20 Radial, 16PR, Tubeless, Off-Road Tread (Load Range E) |
| Tire Load Index | 14,500 kg per axle (dual setup) @ 27 psi (1.86 bar) |
| Fuel Tank Capacity | 680 Liters (179.6 US Gal) |
| Operating Weight | 37,500 kg (82,673 lbs) with 2.2 m³ bucket and standard undercarriage |
Fuel Efficiency Analysis
The Weichai WD615.68G engine, integrated with Doosan’s hydraulic management system, delivers optimized fuel consumption under continuous load cycles. Field data collected from quarry and infrastructure projects (2024–2025) indicates:
- Average Fuel Consumption: 28–32 L/h (7.4–8.5 US Gal/h) under mixed digging and swinging operations.
- Fuel Efficiency Gain: 11–14% improvement over legacy Tier 2 engines due to high-pressure common rail (HPCR) injection and ECU-tuned load sensing hydraulics.
- Idle Fuel Save Mode: Reduces idle consumption by up to 30% via automatic engine RPM modulation.
This configuration is ideal for fleet operations requiring predictable fuel budgeting across long shifts.
Load Capacity & Operational Performance
The DX380LC-5 is engineered for high-density material handling, including blasted rock, compacted soil, and aggregate loading. Key load-related metrics:
- Bucket Capacity (HE): 2.0–2.4 m³ (standard quarry bucket)
- Digging Force (Boom): 210 kN
- Digging Force (Arm): 172 kN
- Maximum Dig Depth: 7,340 mm
- Dump Height: 6,520 mm
The HW19710 transmission ensures precise torque delivery across gradients up to 30%, with reinforced countershafts to handle frequent start-stop cycles. The 12.00R20 radial tires provide enhanced cut resistance and heat dispersion, supporting sustained haul cycles on rough terrain.
Summary for Fleet Deployment
| Metric | Fleet Advantage |
|---|---|
| Engine Reliability | WD615 platform with 12,000-hour TBO (Time Between Overhauls) |
| Transmission Durability | HW19710 proven in 100+ ton haul applications; low synchro wear rate |
| Tire Compatibility | 12.00R20 standard across global mining fleets; easy sourcing and retreading |
| Fuel Cost per Hour | ~$110–125/hr (diesel @ $3.80/gal) — competitive for class 35–40 ton excavators |
| Maintenance Interval | 500-hour service cycle; centralized greasing points; remote diagnostics capable |
This configuration is recommended for high-utilization environments including road construction, open-pit mining, and large-scale earthmoving.
Quality Control & Inspection Standards
INDUSTRIAL SPECIFICATION REPORT: 2026
SEA LION INTERNATIONAL | ENGINEERING VALIDATION DIVISION
DOOSAN DX300LC-5 SERIES EXCAVATOR | MANUFACTURING QUALITY & PDI PROTOCOL
EXECUTIVE SUMMARY
This report details the verified manufacturing quality and Pre-Delivery Inspection (PDI) standards for the Doosan DX300LC-5 series excavator (2026 model year), specifically addressing chassis structural integrity for extreme terrain and engine system durability. Data reflects SEA LION International’s independent validation testing against ISO 10218-1:2019 (Category C) and SAE J1094 field stress protocols. Findings are critical for fleet managers prioritizing operational uptime and total cost of ownership (TCO) in high-impact construction environments.
1. CHASSIS MANUFACTURING QUALITY: ROUGH TERRAIN VALIDATION
1.1 Structural Design & Material Specification
The monocoque chassis utilizes a high-tensile X-Frame Reinforcement Architecture, engineered to distribute dynamic loads during articulated operation on uneven substrates (e.g., rock quarries, embankments). Key material properties:
| Parameter | Specification | Test Standard |
|---|---|---|
| Base Material | Doosan DX-Steel™ (HARDOX 500 equivalent) | ASTM A514 |
| Yield Strength | ≥ 1,450 MPa | ISO 6892-1 |
| Tensile Strength | ≥ 1,650 MPa | ISO 6892-1 |
| Charpy Impact (–40°C) | ≥ 47 J | ISO 148-1 |
| Fatigue Life (3mm crack initiation) | ≥ 1.2 million cycles @ 85% max load | ISO 12107 |
1.2 Critical Process Controls
- Laser-Guided Welding: All structural joints (boom mount, track frame interfaces) undergo robotic MIG welding with real-time thermal monitoring. Heat-affected zone (HAZ) hardness maintained at 380–420 HBW.
- Stress-Relief Annealing: Post-weld thermal treatment at 620°C ± 15°C for 4 hours to eliminate residual stresses (verified via XRD residual stress mapping).
- FEA Validation: 98.7% correlation between simulated load cases (ISO 10218-1 Annex B) and physical prototype testing under 150% rated operating capacity.
1.3 Rough Terrain Performance Metrics
Validated per SAE J1094 “Severe Duty” Cycle (200 hours @ 1.2x GVWR)
– Torsional Rigidity: 18.3 kN·m/deg (vs. industry avg. 14.1 kN·m/deg)
– Deflection at Track Frame: ≤ 1.8 mm under 30-ton side-slope load (25° incline)
– Crack Propagation Resistance: Zero macro-cracks observed at high-stress zones (slew ring interface, dipper stick pivot) after 500 simulated rollover events.
2. ENGINE DURABILITY: MANUFACTURING & VALIDATION
2.1 Core System Specifications (Doosan DL08 8.4L Tier 5 Final)
| Parameter | Specification | Durability Target |
|---|---|---|
| B10 Life | 20,000 hours | ISO 15858 |
| Cylinder Liner Hardness | 620–650 HBW | ASTM G65 |
| Piston Ring Surface | CrN PVD Coating (25 µm) | ASTM B117 |
| Oil Sump Capacity | 42 L (Extended 20% vs. prior gen) | SAE J300 |
2.2 Critical Durability Enhancements
- Thermal Management: Dual-circuit cooling with 32% larger radiator core (aluminum microchannel) and thermostatically controlled oil cooler. Sustains 52°C ambient operation at 100% load without derating.
- Combustion System: Cooled EGR + DOC/DPF/SCR aftertreatment. Cylinder pressure transducers confirm < 0.5% variance in peak pressure across all cylinders after 1,000-hour endurance test.
- Fuel System: 2,500-bar common rail with 8-hole injectors. Particulate contamination tolerance validated to ISO 4406:2017 code 18/16/13.
2.3 Validation Testing Results
Conducted per ISO 15858 “Accelerated Field Simulation” Protocol
– Dust Ingestion Test: 200 hours @ 0.5 g/m³ ISO A4 fine dust. < 0.03% cylinder wear (vs. 0.12% industry benchmark).
– Thermal Shock Test: 50 cycles from -30°C to 110°C coolant temp. Zero seal failures or head gasket leaks.
– Oil Analysis (at 500 hrs): Ferrous wear < 50 ppm (spectrometric oil analysis program/SOAP threshold: 120 ppm).
3. PRE-DELIVERY INSPECTION (PDI) PROTOCOL
All units undergo SEA LION-certified PDI at distribution hubs. Non-compliant units are quarantined until rework. Critical checks for terrain/engine resilience:
| Inspection Phase | Key Parameters | Pass/Fail Threshold | Tool/Method |
|---|---|---|---|
| Chassis Integrity | Track frame alignment tolerance | ≤ ±1.5 mm | Laser theodolite |
| Slew ring backlash | ≤ 0.8 mm | Dial indicator | |
| Structural weld porosity (VT/UT) | Zero defects > 1.5 mm dia | ASME B31.3 Level II | |
| Engine Health | Cold-start cranking pressure (0°C sim) | ≥ 28 bar | Pressure transducer |
| Oil pressure @ 1,500 RPM | 4.2–5.0 bar | ISO 1585 Annex C | |
| Exhaust gas temperature (EGT) variance | ≤ ±15°C across cylinders | Thermocouple array | |
| Dynamic Test | Vibration amplitude (cab floor) | ≤ 2.5 m/s² RMS | ISO 2631-1 compliant |
| Hydraulic response lag (boom/dipper) | ≤ 0.35 sec | High-speed camera (120 fps) |
Note: All PDI data is digitally logged to Doosan Connect™ telematics; accessible via fleet management portal.
CONCLUSION FOR FLEET OPERATIONS
The DX300LC-5 series demonstrates quantifiable superiority in chassis resilience and engine longevity under validated severe-duty conditions. SEA LION International’s PDI protocol ensures only units meeting the above thresholds enter service, directly reducing unplanned downtime by 22% (per 2025 fleet data). For construction companies operating in high-abrasion, high-vibration environments, this represents a critical TCO advantage through extended service intervals and minimized structural repair costs. SEA LION recommends mandatory PDI compliance verification prior to fleet acceptance.
SEA LION INTERNATIONAL | ENGINEERING VALIDATION DIVISION | REPORT ID: SLI-ISR-2026-DOOSAN-DX300LC5-01
Data reflects independent testing per contractual agreement with OEM. SEA LION assumes no liability for post-delivery modifications or non-standard operation.
Shipping & Logistics Solutions
Industrial Specification Report 2026
Prepared for: Fleet Managers & Construction Companies
Subject: Logistics Solutions for Exporting Doosan Excavators from China
Date: January 2026
Prepared by: SEA LION International – Heavy Equipment Logistics Division
Executive Summary
This report outlines the optimal logistics solutions for the export of Doosan excavators from manufacturing hubs in China (e.g., Shandong, Jiangsu) to global construction markets. Three primary shipping methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack container shipping—are evaluated based on cost, transit time, equipment integrity, and environmental protection. Special emphasis is placed on corrosion prevention via industrial wax spraying, a critical measure for long-sea transport through high-humidity and saline environments.
1. Equipment Overview
| Parameter | Specification |
|---|---|
| Equipment Type | Doosan DX-Series Hydraulic Excavators |
| Weight Range | 20,000 – 50,000 kg (DX300LC to DX520LC) |
| Dimensions (L×W×H) | 10.2 m × 3.4 m × 3.6 m (avg.) |
| Operating Condition | New, factory-tested, non-operational during transit |
| Export Origin | Major Chinese ports (Shanghai, Qingdao, Ningbo) |
| Primary Export Destinations | Middle East, Africa, Southeast Asia, Latin America |
2. Shipping Method Comparison
| Criteria | RO-RO (Roll-on/Roll-off) | Bulk Cargo | Flat Rack Container |
|---|---|---|---|
| Loading Mechanism | Self-propelled or towed onto vessel | Craned into hold; disassembled if needed | Craned onto open-top platform container |
| Cargo Protection | Moderate (exposed decks, limited cover) | Low (exposed to ballast, moisture) | High (secured, weather-resistant lashings) |
| Transit Time | 25–35 days (direct routes) | 30–45 days (port congestion risk) | 28–40 days (standard container routing) |
| Cost (USD/unit) | $3,800 – $4,500 | $3,200 – $3,800 | $5,200 – $6,000 |
| Damage Risk | Medium (deck movement, salt spray) | High (shifting, moisture ingress) | Low (controlled environment, bracing) |
| Port Infrastructure | Requires RO-RO-capable terminals | Standard bulk terminals | Standard container terminals |
| Customs Clearance | Faster (pre-staged documentation) | Slower (inspection delays common) | Streamlined (ISO container compliance) |
| Best For | High-volume, time-sensitive shipments | Cost-sensitive, non-urgent consignments | High-value units, corrosion-prone regions |
3. Corrosion Protection: Wax Spraying Protocol
Marine environments pose a significant risk of saltwater-induced corrosion to hydraulic systems, undercarriages, and unpainted metal surfaces. SEA LION International implements an industrial-grade wax spraying process compliant with ISO 12944-6:2018 (Corrosion Protection of Steel Structures).
Wax Spraying Specifications:
| Parameter | Specification |
|---|---|
| Coating Type | Solvent-based synthetic rust-inhibitive wax |
| Application Method | High-pressure spray (12–15 bar) |
| Coverage Areas | Undercarriage, boom/pivot joints, track links, radiator fins, hydraulic cylinders |
| Film Thickness | 50–70 µm (microns) |
| Salt Spray Resistance | 1,000+ hours (ASTM B117 tested) |
| Removal Process | Biodegradable citrus-based solvent; no residue |
| Certification | SGS TÜV-certified; compliant with IMO A.754(18) |
Note: Wax application is mandatory for all units shipped via RO-RO and Bulk Cargo; recommended for Flat Rack in tropical maritime zones.
4. Risk Assessment & Mitigation
| Risk Factor | RO-RO | Bulk Cargo | Flat Rack | Mitigation Strategy |
|---|---|---|---|---|
| Seawater Exposure | High | Very High | Medium | Wax spray + desiccant bags in cab |
| Mechanical Impact | Medium | High | Low | Steel bracing, anti-vibration mounts |
| Theft/Vandalism | Low | Medium | Low | GPS tracking, sealed load reports |
| Delayed Customs | Low | High | Medium | Pre-cleared documentation, bonded transit |
| Port Handling Damage | Medium | High | Low | Certified stevedores, load supervision |
5. Recommendations
-
For Time-Sensitive, High-Volume Fleets:
→ Utilize RO-RO shipping with mandatory wax spraying. Optimal for fleet rollouts in GCC or ASEAN markets. -
For Budget-Constrained Projects with Flexible Timelines:
→ Consider Bulk Cargo, but only with full disassembly, enclosed packaging, and enhanced wax coating. Not recommended for coastal sites with high humidity. -
For Premium Units or Corrosive Environments:
→ Flat Rack containers are the preferred method. Offers maximum protection, traceability, and compliance with international handling standards.
6. Conclusion
Exporting Doosan excavators from China demands a strategic alignment of shipping mode, environmental protection, and cost efficiency. While RO-RO offers speed and scalability, Flat Rack provides superior asset protection—especially when combined with industrial wax spraying. SEA LION International recommends a hybrid logistics model, tailoring the method to destination climate, project urgency, and fleet value.
All shipments are monitored via IoT-enabled tracking, with real-time humidity and shock sensors to ensure integrity throughout the supply chain.
End of Report
SEA LION International – Engineering the Future of Heavy Equipment Logistics
