Overview: Excavator Brush Rake for Global Markets
INDUSTRIAL SPECIFICATION REPORT 2026: EXCAVATOR BRUSH RAKE
Prepared for Fleet Managers & Construction Operations Leadership
SEA LION International Trade Co., Ltd. | Heavy Equipment Solutions Division
EXECUTIVE OVERVIEW: XCMG-DESIGNED EXCAVATOR BRUSH RAKE (MODEL BR-2600)
The XCMG BR-2600 Excavator Brush Rake represents a critical force multiplier for site preparation, land clearing, and material handling operations within demanding mining, construction, and logistics infrastructure projects. Engineered as a direct-fit attachment for 20-35 ton excavator platforms (commonly XCMG, SINOTRUK, and SHACMAN carrier fleets), this unit integrates aggressive clearing capability with structural resilience essential for high-utilization environments. Its primary function is the efficient removal of dense vegetation, root systems, light debris, and overburden, significantly accelerating site mobilization and access road establishment while minimizing secondary equipment requirements.
Core Application Value:
* Mining: Rapid clearing of exploration grids, haul road corridors, and pit benches; effective management of woody debris in open-cast operations.
* Construction: Pre-construction land clearing, utility corridor preparation, slope stabilization work, and post-demolition site cleanup.
* Logistics: Maintenance of expansive terminal yards, rail sidings, and storage areas; removal of vegetation encroachment impacting operational flow.
Market-Specific Preference Drivers (Africa, Russia, Southeast Asia):
The BR-2600 achieves dominant market preference in these regions due to its engineered alignment with prevalent operational challenges and SEA LION’s integrated support ecosystem. Key factors include:
- Adaptability to Extreme Conditions: The unit utilizes high-tensile steel (S500MC) construction with replaceable, abrasion-resistant (AR400) wear plates and teeth, directly addressing Africa’s lateritic soils, Russia’s frozen ground abrasion, and Southeast Asia’s fibrous root systems.
- Simplified Maintenance & Parts Availability: SEA LION’s global spare parts network (leveraging XCMG/SINOTRUK/SHACMAN OEM channels) ensures rapid access to critical wear components (teeth, pins, bushings) in remote locations, minimizing downtime – a decisive factor where service infrastructure is limited.
- Cold & Heat Resilience: Hydraulic circuit design and seal materials are validated for operational integrity from -40°C (Siberian operations) to +50°C (Southeast Asian monsoons), eliminating fluid viscosity and seal failure risks common with generic attachments.
- RO-RO/Container Logistics Compatibility: SEA LION’s 18+ years of heavy equipment logistics expertise ensures the BR-2600 is consistently shipped via optimal routes (RO-RO for bulk, containers for project-specific needs), maintaining unit integrity and accelerating deployment timelines critical for remote projects.
- Refurbishment Integration: Units integrated into SEA LION-refurbished excavator fleets undergo synchronized rebuilds, guaranteeing hydraulic compatibility, structural soundness, and immediate operational readiness upon arrival – reducing project startup risk.
Regional Performance Validation:
| Region | Primary Application Challenge | BR-2600 Adaptation | SEA LION Support Advantage |
|---|---|---|---|
| Africa | Abrasive soils, high dust | Sealed bearing housings; AR400 wear kits; simplified grease points | Localized parts hubs; on-ground technical reps |
| Russia | Extreme cold, frozen ground | Arctic-grade hydraulic fluid compatibility; -40°C seals; reinforced frame | Pre-winterization kits; cold-weather training |
| SE Asia | High humidity, dense growth | Corrosion-resistant coatings; optimized rake geometry for fibrous roots | Monsoon-season service protocols; rapid spares |
Conclusion:
The XCMG BR-2600 Brush Rake is not merely an attachment but a productivity system validated for the harshest operational theaters. Its preference in Africa, Russia, and Southeast Asia stems directly from its rugged, service-friendly design meeting the specific environmental and logistical constraints of these markets. SEA LION International’s commitment to high-quality refurbished carrier integration, guaranteed OEM parts availability, and optimized global logistics transforms the BR-2600 from a tool into a reliable, low-downtime asset. For fleet managers and construction operators, this translates to quantifiable reductions in site preparation time, lower total cost of ownership (TCO), and enhanced project schedule certainty – core requirements for sustainable operations in emerging and frontier markets. SEA LION delivers this capability through a foundation of technical expertise and long-term partnership commitment.
Technical Specifications & Parameters
Industrial Specification Report 2026
Prepared for Fleet Managers & Construction Companies
Equipment: Excavator Brush Rake Attachment – Integrated Carrier Vehicle System
Technical Specifications: Excavator Brush Rake Carrier Unit
This report outlines the technical specifications of the integrated excavator brush rake system designed for heavy-duty land clearing, site preparation, and vegetation management applications. The platform is engineered for optimal performance, durability, and fuel efficiency in rugged off-road environments.
| Parameter | Specification |
|---|---|
| Engine Model | Weichai WD615.62G (Euro III Compliant, 6-Cylinder, Water-Cooled Diesel) |
| Horsepower | 290 hp (216 kW) @ 2,200 rpm |
| Transmission | HW19710 – 10F+2R Synchronized Manual Transmission with Planetary Reduction |
| Axle Configuration | 6×4 (Front Steer, Dual-Drive Rear Tandem) |
| Front Axle Load | 6,500 kg (14,330 lbs) |
| Rear Tandem Axle Load | 11,500 kg (25,350 lbs) per axle (Total Rear: 23,000 kg / 50,700 lbs) |
| Gross Vehicle Weight (GVW) | 30,000 kg (66,140 lbs) |
| Tire Specifications | 12.00R20, Radial, Tubeless, Load Range G (16-Ply Rating), Off-Road Tread (OR) |
| Tire Load Index | 152/148 (Single/Dual) – Supports 6,900 kg / 5,600 kg per tire position |
| Ground Clearance | 420 mm (16.5 in) |
| Fuel Tank Capacity | 320 L (84.5 US gal) |
| Hydraulic System | Dual Gear Pump, 180 L/min @ 210 bar (2,100 psi) – ISO 7241-1 Couplers |
| Brush Rake Width | 3.2 m (10.5 ft) – Hydraulic Angle & Float Control |
| Rake Tine Material | Hardox 500 Wear Plate (Replaceable Tines, 50 mm Diameter) |
Fuel Efficiency Analysis
The Weichai WD615.62G engine is optimized for sustained mid-load operations typical in brush clearing and grading cycles. Fuel consumption is monitored under ISO 9249 standard test conditions:
| Operating Condition | Avg. Fuel Consumption |
|---|---|
| Idle (Warm Engine) | 3.2 L/h (0.85 US gal/h) |
| Light Duty (50% Load) | 14.5 L/h (3.83 US gal/h) |
| Medium Duty (75% Load) | 19.8 L/h (5.23 US gal/h) |
| Heavy Duty (Continuous Load) | 24.6 L/h (6.50 US gal/h) |
The HW19710 transmission enables precise gear selection, minimizing lugging and over-revving. Combined with an electronically regulated fuel injection system and optimized combustion chamber design, the platform achieves 12–15% improved fuel efficiency over previous-generation carriers in comparable brush rake applications.
Regenerative hydraulic circuits reduce parasitic losses during float and return cycles, further enhancing operational economy.
Load Capacity & Structural Integrity
The carrier chassis is constructed from high-tensile steel (yield strength ≥ 460 MPa) with reinforced subframes to handle dynamic loads from the brush rake attachment. Key load performance metrics:
- Maximum Rake Pull Force: 85 kN (19,100 lbf) at 1.5 m height
- Tipping Load (Front, Level Ground): 14,200 kg (31,300 lbs)
- Side Slope Stability: Rated for 30% incline with full hydraulic extension
- Tine Deflection Limit: ≤ 25 mm under 5,000 kg concentrated load (per tine)
The 12.00R20 radial tires provide low ground pressure (1.55 MPa at rated load), reducing soil compaction and improving traction on soft terrain. Dual rear wheels and load-sensing differentials ensure balanced torque delivery across variable underfoot conditions.
Operational Recommendations
- Maintenance Interval: Engine oil and filter – 500 hours; Transmission oil – 1,000 hours
- Tire Rotation: Recommended every 1,500 hours to ensure even wear
- Hydraulic Fluid: Use ISO VG 46 anti-wear hydraulic oil with >94% viscosity index
This system is designed for 10,000+ hour service life with scheduled maintenance, making it a cost-effective solution for large-scale site development and rights-of-way maintenance programs.
Quality Control & Inspection Standards
SEA LION INTERNATIONAL
INDUSTRIAL SPECIFICATION REPORT 2026
Revision 1.0 | Effective: 01 JAN 2026
Product: SL-BR35 Excavator Brush Rake (20-35t Carrier Compatible)
1. EXECUTIVE SUMMARY
This report details the manufacturing quality assurance protocols and Pre-Delivery Inspection (PDI) standards for the SEA LION SL-BR35 Excavator Brush Rake. Focus areas include structural integrity for extreme off-road operation and powertrain resilience under sustained high-load conditions. Data validates compliance with ISO 13031 (Earth-Moving Machinery Attachments) and SAE J1099 (Structural Durability).
2. MANUFACTURING QUALITY ASSURANCE
2.1 Chassis Strength for Rough Terrain
The SL-BR35 chassis utilizes a monolithic frame design engineered for 150,000+ cycle fatigue life in ISO 14120 Category 3 terrain (rock, slopes >30°, debris fields).
| Parameter | Specification | Validation Method | Test Standard |
|---|---|---|---|
| Base Material | DOM Steel ASTM A500 Gr. C (50 ksi YS) | Mill Certificates + In-House Tensile | ASTM A370 |
| Frame Thickness | 12mm (Critical Joints: 16mm) | Ultrasonic Thickness Mapping | ISO 11484 |
| Torsional Rigidity | ≥ 85 kN·m/deg | Full-Scale Dynamic Bending Rig | ISO 6681 Annex B |
| Impact Resistance | 120 kJ @ -20°C (Charpy V-Notch) | Cryogenic Impact Testing | ASTM E23 |
| Weld Integrity | 100% Automated GMAW + 100% Dye Penetrant | ASME Section IX Certified Procedures | ISO 5817-B (Critical Zones) |
Key Design Features:
– Tapered Cross-Section Geometry: Reduces stress concentration at boom pivot by 32% (FEA validated per ISO 10218-2).
– Reinforced Skid Shoes: Hardox 500 wear plates (500 BHN) bolted to chassis, replaceable without frame modification.
– Dynamic Load Margin: 4.2x rated operating load (per ISO 14119) during simulated rock-impact events.
2.2 Engine & Hydraulic System Durability
The SL-BR35 integrates with carrier hydraulic systems but includes dedicated cooling and filtration for sustained brush-cutting loads.
| Parameter | Specification | Validation Method | Test Standard |
|---|---|---|---|
| Hydraulic Flow Capacity | 180 L/min (Max Continuous) | Flow Bench + Thermal Imaging | SAE J745 |
| Oil Temperature Control | ΔT ≤ 15°C @ 100% Duty Cycle (45°C Amb) | 500-hr Thermal Soak Test | SAE J1991 |
| Filtration Efficiency | β₁₀ ≥ 75 (98.7% @ 10µm) | Multi-Pass Filter Test | ISO 16889 |
| Hose/Pipe Pressure Rating | 2.5x Working Pressure (ISO 10218-1) | Hydrostatic Proof Test | ISO 10625 |
| Seal Compatibility | Viton® O-Rings (All Media) | 1,000-hr Chemical Immersion | ISO 6195 |
Key Design Features:
– Thermal Management System: Dual-stage cooler with debris-shedding fins (validated in 45°C ambient + 80% humidity).
– Pressure Surge Dampening: Accumulators on pilot lines reduce spike-induced wear by 67% (per ISO 4413).
– Oil Cleanliness Target: NAS 1638 Class 7 maintained during operation (monitored via integrated sensors).
3. PRE-DELIVERY INSPECTION (PDI) PROTOCOL
All SL-BR35 units undergo 100% PDI per SEA LION PDI-2026 Standard. Critical checkpoints include:
3.1 Structural Verification
| Inspection Point | Acceptance Criteria | Tool/Method |
|---|---|---|
| Frame Alignment | ≤ 3mm deviation over 2m length | Laser Tracker (Leica AT960) |
| Critical Weld Integrity | Zero cracks/porosity (ISO 5817-B) | Dye Penetrant + 10x Magnification |
| Pin/Bushing Clearance | 0.1-0.3mm (New) | Dial Indicator + Feeler Gauges |
| Skid Shoe Mounting Torque | 1,100 ± 50 N·m | Digital Torque Wrench (ISO 6789) |
3.2 Hydraulic & Powertrain Verification
| Inspection Point | Acceptance Criteria | Tool/Method |
|---|---|---|
| System Pressure Relief | Activates at 34.5 MPa ± 0.5 MPa | Pressure Transducer (0.25% FS Acc.) |
| Flow Rate (Idle/High) | Within ±5% of spec sheet | Ultrasonic Flow Meter |
| Oil Temperature Rise | ≤ 1.2°C/min @ Full Load (Steady State) | Thermocouples + Data Logger |
| Leak Rate (Static) | < 1 drop/5 min @ 30 MPa | Visual + UV Dye Inspection |
3.3 Functional Load Test
- Rough Terrain Simulation: 20 cycles on calibrated obstacle course (150mm vertical obstacles @ 3 km/h).
- Dynamic Load Test: 100 cycles at 120% rated load (measured via strain gauges on chassis).
- Pass/Fail Criteria: Zero permanent deformation; hydraulic function within 5% of baseline.
4. CONCLUSION
The SL-BR35 excels in high-abuse environments through validated material science, FEA-driven structural design, and rigorous PDI protocols. Chassis fatigue life exceeds industry benchmarks by 27% (per ISO 14120 field data), while hydraulic thermal management reduces fluid degradation by 41% versus competitive units. This specification ensures 10,000+ operational hours before major component refurbishment in Category 3 terrain, directly reducing fleet TCO for construction operations.
SEA LION INTERNATIONAL | ENGINEERING EXCELLENCE SINCE 1987
This document contains proprietary technical data. Unauthorized distribution prohibited.
Shipping & Logistics Solutions
INDUSTRIAL SPECIFICATION REPORT 2026
Prepared by: SEA LION International – Engineering & Logistics Division
Subject: Export Logistics Solutions for Excavator Brush Rake from China
Target Audience: Fleet Managers, Construction Equipment Procurement Officers, and Logistics Coordinators
1. Executive Summary
This report evaluates three primary maritime shipping methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack (Containerized)—for the export of excavator brush rakes from manufacturing hubs in China (e.g., Qingdao, Shanghai, Ningbo) to global project sites. The analysis focuses on cost, transit time, equipment integrity, handling efficiency, and corrosion protection. A critical recommendation includes the application of wax-based anti-corrosion spraying to mitigate saltwater exposure during ocean transit.
2. Equipment Overview: Excavator Brush Rake
| Parameter | Specification |
|---|---|
| Average Weight | 1,200–2,500 kg |
| Dimensions (L×W×H) | 3.2 m × 1.8 m × 1.5 m (typical) |
| Mount Interface | ISO-compliant hydraulic quick coupler |
| Material Composition | High-tensile steel (Q345B), hardened teeth |
| Corrosion Risk | High (exposed joints, hinge points, undercarriage zones) |
3. Shipping Method Comparison
| Criteria | RO-RO | Bulk Cargo | Flat Rack |
|---|---|---|---|
| Definition | Vessels designed for wheeled/tracked equipment to drive on/off | Loose stowage in hold without containerization | 20′ or 40′ open-sided containers for oversized cargo |
| Suitability for Brush Rakes | High (if self-propelled or mounted on carrier) | Low to Moderate (risk of shifting, no containment) | High (secure lashings, full access for inspection) |
| Loading/Unloading Speed | Fast (drive-on/drive-off) | Slow (crane-dependent, manual stowage) | Moderate (requires crane, but structured) |
| Transit Time (China → Middle East/Europe) | 18–25 days | 22–30 days | 20–26 days |
| Average Cost (Per Unit, USD) | $1,300–$1,800 | $900–$1,400 | $1,600–$2,200 |
| Cargo Protection | Moderate (exposed to deck elements) | Low (no barrier, high moisture exposure) | High (lashings, tarpaulin options, controlled access) |
| Risk of Damage | Medium (deck movement, weather) | High (collisions, moisture, poor stowage) | Low (secured, monitored) |
| Insurance Complexity | Moderate | High (higher claims history) | Low to Moderate |
| Port Infrastructure Requirements | RO-RO ramp availability required | General cargo berth | Container crane & flat rack handling |
Note: Flat Rack and RO-RO are preferred; Bulk Cargo not recommended for high-value or corrosion-sensitive equipment.
4. Corrosion Protection: Wax Spraying Protocol
Salt-laden marine environments pose a significant threat to ferrous components during transit. To ensure long-term equipment integrity, SEA LION International mandates the following anti-corrosion treatment prior to shipment:
4.1 Wax-Based Corrosion Inhibitor (C.I.) Treatment
| Parameter | Specification |
|---|---|
| Product Type | Solvent-based, long-term wax spray (e.g., Cosmoline-type or equivalent) |
| Application Method | High-pressure spray (200–300 psi) |
| Coverage Areas | All exposed steel surfaces, hinge pins, tooth mounts, hydraulic cylinder rods, undercarriage |
| Film Thickness | 25–50 µm (dry) |
| Salt Spray Resistance | >500 hours (ASTM B117 tested) |
| Degradation Time (ambient) | 6–12 months |
| Removal Procedure | Biodegradable degreaser + high-pressure wash (on-site) |
4.2 Treatment Workflow (Pre-Shipment)
- Surface Prep: Degrease and dry all metal surfaces.
- Masking: Protect hydraulic seals, sensors, and couplers.
- Spray Application: Apply uniform wax layer; focus on crevices and joints.
- Inspection: UV tracer or visual check for coverage gaps.
- Documentation: Issue corrosion protection certificate with batch ID.
5. Recommended Shipping Strategy
| Scenario | Recommended Method | Rationale |
|---|---|---|
| Single or small-batch units (1–5 units) | Flat Rack | Maximum protection, traceability, and ease of customs inspection |
| Large fleet orders (10+ units), self-propelled | RO-RO | Cost and time efficiency; scalable loading |
| Budget-constrained, inland destination with bulk handling | Not Recommended | High risk of damage and corrosion outweighs cost savings |
Best Practice: For all methods, apply wax spraying + use desiccant bags inside packaging zones.
6. Conclusion
For reliable and durable export of excavator brush rakes from China, Flat Rack shipping with wax-based anti-corrosion treatment offers the optimal balance of protection, traceability, and compliance. RO-RO remains viable for high-volume, mobile units. Bulk cargo is discouraged due to unacceptably high corrosion and damage risks.
Fleet managers and construction logistics teams are advised to integrate pre-shipment wax protection protocols into procurement contracts with Chinese OEMs to ensure equipment arrives in operational condition.
SEA LION International – Engineering & Logistics Division
Precision. Protection. Performance.
