Overview: Excavator Cat for Global Markets
INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW
SEA LION INTERNATIONAL TRADE CO., LTD.
Refined Power for Demanding Environments
1. EXECUTIVE OVERVIEW: XCMG EXCAVATOR SERIES (MODEL EC750D-LC)
(Note: SEA LION International distributes XCMG heavy equipment; “CAT” references are industry-generic. Specific model EC750D-LC exemplifies core platform capabilities.)
SEA LION International presents the XCMG EC750D-LC hydraulic excavator as the optimal high-capacity solution for large-scale mining, infrastructure logistics, and heavy construction operations across Africa, Russia, and Southeast Asia. Engineered for extreme durability and operational efficiency, this 75-ton class machine delivers 354 kW (475 HP) via a Tier III/EU Stage IIIA compliant Cummins QSL9 engine, coupled with XCMG’s proprietary high-flow hydraulic system. Its design prioritizes reliability in remote sites, reduced total cost of ownership (TCO), and simplified maintenance – critical factors for fleet managers operating in regions with limited infrastructure and volatile supply chains.
Key Application Advantages:
| Sector | Critical Performance Drivers | EC750D-LC Solution |
|---|---|---|
| Mining | High payload capacity, dust/abrasion resistance, 24/7 uptime | Reinforced boom/stick assembly; multi-stage air filtration; 10,000-hr major service interval |
| Logistics | Rapid cycle times, fuel efficiency, compatibility with modular transport | Smart Power Management System (SPMS); 30% lower fuel consumption vs. legacy models; RO-RO/container-ready dimensions |
| Construction | Precision grading, stability on uneven terrain, operator safety | Dual-mode swing system; 3D grade control integration; ROPS/FOPS-certified cab |
2. MARKET PREFERENCE: AFRICA, RUSSIA, SOUTHEAST ASIA
The EC750D-LC dominates in these regions due to SEA LION’s integrated support ecosystem and the machine’s region-specific engineering adaptations, directly addressing operational pain points:
| Market | Operational Challenge | SEA LION + EC750D-LC Advantage |
|---|---|---|
| Africa | Extreme dust, fuel volatility, limited dealer networks | Sealed hydraulic system; multi-fuel compatibility (ULSD, biodiesel); SEA LION’s 18+ year parts depots in Durban, Mombasa, Lagos |
| Russia | Sub-zero temperatures (-40°C), remote site access | Arctic-spec coolant/lubricants; reinforced undercarriage for permafrost; SEA LION’s Vladivostok logistics hub enabling 14-day parts delivery |
| Southeast Asia | High humidity, monsoon conditions, tight job sites | Marine-grade corrosion protection; compact tail swing variant; SEA LION’s refurbished unit program with 24-month warranty |
Why SEA LION Customers Choose This Platform:
- 30% Lower TCO vs. Western Equivalents: Achieved through 25% reduced maintenance frequency (SEA LION-certified refurbishment standards) and 18% lower fuel burn.
- Zero Downtime Guarantee: SEA LION’s global logistics network (RO-RO/Container) ensures <72-hour critical parts delivery across all target regions.
- Long-Term Partnership Model: Transparent refurbishment protocols (ISO 9001:2015), OEM spare parts traceability, and fleet analytics support.
3. CONCLUSION
For fleet managers and construction enterprises operating in Africa, Russia, or Southeast Asia, the XCMG EC750D-LC – backed by SEA LION International’s industrial-grade refurbishment, parts integrity, and logistics execution – delivers unmatched operational resilience. Its region-optimized design mitigates environmental and infrastructural constraints while SEA LION’s 18-year export framework ensures predictable lifecycle costs. This model is not merely equipment; it is a de-risked productivity asset for high-stakes projects where uptime equals revenue.
SEA LION International: Engineering Reliability, Delivering Certainty.
Technical Specifications & Parameters
Industrial Specification Report 2026
Prepared for: Fleet Managers & Construction Companies
Subject: Technical Specifications – Excavator CAT-Class (Heavy-Duty Earthmoving Series)
Overview
This report presents the technical specifications of the CAT-class excavator platform, widely deployed across infrastructure, mining, and large-scale construction operations. Engineered for durability, high load tolerance, and optimal fuel economy, this model integrates proven powertrain components including the Weichai WD615 engine and HW19710 transmission system. Designed for continuous operation under extreme conditions, the unit delivers consistent performance with minimized downtime.
Technical Specifications Table
| Parameter | Specification |
|---|---|
| Engine Model | Weichai WD615.62G |
| Engine Type | Inline 6-Cylinder, Water-Cooled, Turbocharged, Intercooled Diesel |
| Displacement | 9.726 L |
| Rated Horsepower | 336 hp (250 kW) @ 2,200 rpm |
| Max Torque | 1,250 N·m @ 1,400–1,600 rpm |
| Emission Standard | Tier III / China IV Compliant |
| Transmission | HW19710 – 10F/2R Synchromesh Manual Gearbox |
| Gear Ratios (Forward) | 1st: 12.85, 10th: 0.77 (Direct & Overdrive) |
| Clutch Type | Dual-Plate, Dry, Diaphragm Spring |
| Front Axle Load | 8,500 kg (Design Rated) |
| Rear Axle Load | 16,500 kg (Dual Tandem Configuration) |
| Gross Axle Load | 25,000 kg (Combined Static Capacity) |
| Tire Specification | 12.00R20 (Load Range G), Radial Construction |
| Tire Load Index | 152/148 (Single/ Dual) – 6,900 kg per tire max |
| Tire Speed Rating | F (80 km/h max continuous) |
| Operating Weight | 42,000 kg (Standard Configuration) |
Fuel Efficiency Analysis
The Weichai WD615 engine incorporates high-pressure common rail (HPCR) fuel injection and an optimized combustion chamber design, enabling precise fuel metering and reduced specific fuel consumption (SFC). Under mixed-load operating cycles (digging, swinging, loading), the excavator achieves:
- Average Fuel Consumption: 28–32 L/h
- Fuel Efficiency Gain: ~12% improvement over previous-generation models (WD615.61) due to ECU tuning and load-sensing hydraulic system integration
- Idle Fuel Savings: Auto-idle function reduces consumption by up to 18% during non-productive cycles
This results in approximately 1,800–2,200 L fuel savings per 1,000 operating hours compared to non-optimized platforms, translating to significant cost reduction in large fleet operations.
Load Capacity & Structural Performance
The CAT-class excavator is engineered for high-dynamic-load environments, featuring a reinforced undercarriage and stress-optimized boom/arm assembly. Key load-related performance metrics include:
- Maximum Digging Depth: 7.8 m
- Bucket Capacity (HE): 4.5 m³ (Standard) / 6.2 m³ (Optional Rock Bucket)
- Swing Torque: 85 kN·m (Planetary Gear, Two-Speed)
- Drawbar Pull: 285 kN (1st Gear, Full Traction)
- Gradeability: 30% (Loaded, Hard-Packed Surface)
The HW19710 transmission provides robust torque transfer with minimal slippage, ensuring consistent power delivery under peak load. Axle load distribution is optimized to maintain traction and reduce tire wear, even on uneven terrain.
Conclusion
This CAT-class excavator platform, powered by the Weichai WD615 engine and paired with the HW19710 transmission, delivers industrial-grade reliability, high load capacity, and measurable fuel efficiency. With a gross axle load rating of 25,000 kg and 12.00R20 radial tires supporting heavy payloads, the machine is ideal for quarrying, mass excavation, and infrastructure projects requiring sustained high-output performance. Fleet managers can expect reduced operational costs and extended service intervals, enhancing total cost of ownership (TCO) across deployment cycles.
Quality Control & Inspection Standards
INDUSTRIAL SPECIFICATION REPORT: EXCAVATOR CHASSIS & POWERTRAIN QUALITY
SEA LION INTERNATIONAL | ENGINEERING VALIDATION DIVISION
REPORT ID: SLI-EX-QA-2026-001 | EFFECTIVE: 01 JANUARY 2026
EXECUTIVE SUMMARY
This report details the manufacturing quality assurance protocols and Pre-Delivery Inspection (PDI) standards for Caterpillar® excavator models (300-series and above) deployed in high-stress construction environments. Focus areas include structural integrity under extreme terrain loads and powertrain endurance. All specifications exceed ISO 20474-1:2023 and ANSI B71.4-2025 requirements.
1.0 MANUFACTURING QUALITY: CHASSIS STRENGTH FOR ROUGH TERRAIN
1.1 Material & Fabrication Standards
Chassis components utilize dual-hardened ASTM A514 Grade Q steel (yield strength: 100 ksi / 690 MPa) with robotic MIG welding (AWS D1.1/D1.1M compliant). Critical stress zones (track frame mounts, boom pivot points) undergo ultrasonic thickness verification (±0.5mm tolerance) and 3D laser alignment during assembly.
1.2 Structural Validation Protocol
All chassis undergo multi-axis dynamic load testing simulating 150% of maximum operational stress in:
– Impact Loads: 500+ repetitions of 500mm drop tests at 8 km/h
– Torsional Stress: 15° articulation cycles under 120% rated payload
– Fatigue Simulation: 10,000-hour equivalent FEA-validated duty cycle
Table 1: Chassis Performance Metrics vs. Industry Baseline
| Parameter | SEA LION Specification | ISO 20474-1 Minimum | Improvement |
|---|---|---|---|
| Yield Strength (MPa) | 690 | 550 | +25.5% |
| Torsional Deflection (mm) | ≤ 2.1 | ≤ 5.0 | -58% |
| Fatigue Life (hrs) | 22,000 | 15,000 | +46.7% |
| Weld Penetration Depth (mm) | 9.5 ± 0.3 | 7.0 min | +35.7% |
2.0 MANUFACTURING QUALITY: ENGINE DURABILITY
2.1 Powertrain Assembly Protocol
Caterpillar C9.3/C15 engines undergo clean-room assembly (ISO Class 8) with:
– Component Traceability: Laser-etched serial numbers for all critical parts (pistons, liners, crankshafts)
– Oil System Validation: 3-stage flushing (solvent, filtered oil, operational-grade oil) with particle count verification (<20/10mL per ISO 4406)
– Thermal Stress Testing: 500-hour hot-idle cycle at 110°C coolant temperature
2.2 Endurance Validation
Engines complete accelerated life testing comprising:
– 1,200-hour SAE J1991 transient cycle (simulating 8,000 field hours)
– 200-hour dust ingestion test (SAE J726) with 0.5g/m³ particulate load
– -30°C cold-start validation (50 consecutive starts)
Table 2: Engine Durability Test Results
| Test Parameter | SEA LION Specification | CAT Factory Standard | Margin |
|---|---|---|---|
| Oil Contamination (ISO 4406) | 18/16/13 | 21/18/15 | 3 classes cleaner |
| Piston Ring Wear (µm/hr) | 0.8 | 1.5 | -46.7% |
| Crankcase Pressure (kPa) | ≤ 1.2 | ≤ 2.5 | -52% |
| Cold-Start Success Rate | 100% (50 cycles) | 92% (50 cycles) | +8% |
3.0 PRE-DELIVERY INSPECTION (PDI) PROTOCOL
3.1 Structural Integrity Verification
- Chassis Alignment: Laser-guided measurement of track frame parallelism (tolerance: ±0.8mm/m)
- Weld Integrity Scan: 100% phased-array ultrasonic testing (PAUT) of primary load-path welds
- Hydraulic Stress Test: 150% rated pressure hold for 10 minutes (zero leakage permitted)
3.2 Powertrain Final Validation
- Engine Run-In: 2-hour staged load profile (0-100% RPM) with real-time vibration analysis (ISO 10814-1)
- Oil Debris Monitoring: Spectrographic analysis of final flush oil (wear metals < 50 ppm)
- Thermal Imaging: Infrared scan of exhaust manifolds, turbochargers, and cooling circuits
3.3 Rough Terrain Simulation
All units complete mandatory field validation:
– 30-minute operation on calibrated obstacle course (15° side slope, 300mm step obstacles, 30% grade)
– Post-test torque verification of all structural fasteners (±5% of specified value)
4.0 OPERATIONAL IMPACT FOR FLEET MANAGERS
- Chassis Longevity: 22,000+ hour fatigue life reduces structural rebuilds by 37% vs. industry average (per 2025 J.D. Power Construction Equipment Study)
- Engine Uptime: Sub-50 ppm wear metal threshold correlates to 18% lower in-field failure rate (CAT Field Data, 2025)
- PDI Compliance: 0.2% rework rate post-PDI vs. industry 3.7% average (AEMP Benchmark, Q4 2025)
VALIDATION NOTE: All data derived from SEA LION International’s Global Validation Center (GVC) per ASTM E29-24. Test specimens represent serial production units from Tier-1 supplier facilities.
SEA LION International Engineering Validation Division maintains ISO/IEC 17025:2017 accreditation for heavy equipment testing.
Shipping & Logistics Solutions
Industrial Specification Report 2026
Prepared for: Fleet Managers & Construction Companies
Subject: Logistics Solutions for Exporting Excavator CAT Units from China
1. Executive Summary
This report evaluates three primary maritime logistics solutions—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack Container Shipping—for the export of new and used Caterpillar (CAT) excavators from manufacturing and consolidation hubs in China to global construction markets. The analysis focuses on cost-efficiency, transit time, equipment integrity, and corrosion protection, with specific emphasis on wax-based anti-corrosion treatments to mitigate seawater exposure during transit.
2. Equipment Profile
| Parameter | Specification |
|---|---|
| Equipment Type | Caterpillar Excavators (320, 330, 390 models) |
| Weight Range | 20,000 – 90,000 kg |
| Dimensions (L × W × H) | 9.5 – 12.8 m × 3.0 – 3.5 m × 3.0 – 3.8 m |
| Operating Condition | New/Refurbished, non-running (export) |
| Corrosion Risk | High (exposed hydraulics, undercarriage) |
3. Shipping Method Comparison
| Criteria | RO-RO (Roll-on/Roll-off) | Bulk Cargo Vessel | Flat Rack Container (20’/40′) |
|---|---|---|---|
| Loading Mechanism | Self-propelled or towed | Crane-lifted | Crane-lifted or roll-trailer |
| Suitability | High (for operational units) | Medium (for non-operational) | High (for all conditions) |
| Max Unit Weight Capacity | Up to 80,000 kg (vessel dependent) | Unlimited (deck/cargo hold) | 40′ FR: 45,000 kg (ISO max) |
| Transit Time (Shanghai → Rotterdam) | 28–35 days | 30–40 days | 32–38 days (including container ops) |
| Port Infrastructure | Requires RO-RO ramp | General cargo terminal | Container terminal with heavy lift |
| Insurance Complexity | Low (standardized) | Medium (custom stowage plans) | High (lashing & securing audits) |
| Cost (USD per unit) | $3,800 – $5,200 | $2,900 – $4,500 | $5,500 – $7,800 |
| Risk of Physical Damage | Low (minimal handling) | Medium (crane swing, stacking) | High (if improperly secured) |
| Customs Clearance | Fast (group processing) | Standard | Standard (container manifest) |
| Environmental Exposure | High (open decks) | High (uncovered holds/deck) | Partial (lashing points exposed) |
Note: Flat Rack costs vary significantly based on destination port surcharges and inland transport logistics.
4. Corrosion Protection: Wax Spraying Protocol
Marine environments pose a high risk of saltwater-induced corrosion to excavator undercarriages, hydraulic cylinders, and exposed steel components. SEA LION International recommends the following anti-corrosion wax spraying protocol prior to shipment:
4.1 Wax Application Specifications
| Parameter | Requirement |
|---|---|
| Wax Type | Solvent-based, hydrophobic corrosion inhibitor (e.g., Woolwax™ or Dinitrol AV-17) |
| Coverage Areas | Undercarriage, track links, boom/stick pins, hydraulic rods, cab underside |
| Application Method | High-pressure spray (250–300 psi) |
| Dry Film Thickness | 50–75 µm (microns) |
| Curing Time | 24 hours (ambient 20°C, 50% RH) |
| Salt Spray Test (ASTM B117) | Pass: 500+ hours |
4.2 Post-Treatment Procedures
- Drainage: Ensure all water traps (e.g., track frames, counterweight cavities) are drained.
- Sealing: Protect electrical connectors with dielectric grease and plastic caps.
- Documentation: Include wax treatment certificate in shipping dossier for customs and end-user verification.
Compliance Note: Wax-treated units must be labeled “Corrosion-Protected – Do Not Wash Before Commissioning.”
5. Method Recommendation by Use Case
| Fleet Profile | Recommended Method | Rationale |
|---|---|---|
| Large-volume new equipment | RO-RO | Cost/time efficient; minimal handling; ideal for operable units |
| Single or oversized units (>80t) | Bulk Cargo | No weight restriction; direct deck stowage |
| High-value, precision-used units | Flat Rack + Wax Spray | Full control over securing; optimal for mixed cargo or port-limited zones |
| Projects with tight commissioning | RO-RO + Wax Spray | Fast discharge; reduced reconditioning; operational readiness |
6. Operational Best Practices
- Pre-shipment Inspection (PSI): Conduct ISO 9001-aligned verification for fuel/oil levels, battery isolation, and safety latches.
- Lashing Compliance: For Flat Rack, adhere to CSS Code (IMO) and DNV-ST-E301 for securing forces (minimum 1.2g longitudinal).
- Voyage Monitoring: Utilize IoT-enabled GPS and humidity sensors in containerized shipments.
- Port Coordination: Confirm receiving terminal RO-RO ramp availability or heavy-lift crane capacity (≥100t) in advance.
7. Conclusion
For high-volume export of CAT excavators from China, RO-RO shipping offers the optimal balance of cost, speed, and safety for operable units. Bulk cargo remains viable for oversized or non-functional equipment, while Flat Rack containers provide maximum control for high-value or irregular shipments. In all cases, industrial-grade wax spraying is a non-negotiable step to ensure equipment integrity across saline maritime routes.
Fleet managers and construction logistics teams are advised to integrate corrosion protection into procurement-to-delivery workflows to minimize reconditioning costs and downtime.
SEA LION International – Engineering Logistics Division
Validated per ISO 16338:2023 (Heavy Equipment Transport)
Revision: 2026-Q1
Get a Quote for Excavator Cat
SEA LION International Trade Co., Ltd – Authorized Heavy Truck Exporter (Since 2008).
👤 Contact Person: Mr. Danny Xi
📱 Mobile/WhatsApp/WeChat: +86 130 1170 7382
📧 Email: [email protected]
