Overview: Excavator Rake Attachment for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW

Product: SEA LION Series XR Heavy-Duty Excavator Rake Attachment (Models XR-1200 to XR-3500)
Target Applications: Mining Overburden Clearance, Logistics Yard Material Handling, Construction Site Grading & Debris Management

Core Value Proposition

The SEA LION XR Series rake attachment is engineered to significantly enhance material handling efficiency and versatility for excavators (15-50 ton class) operating in high-abrasion, high-volume environments. Unlike standard bucket configurations, the XR Series utilizes a patented dual-plane tine geometry and hardened alloy steel (Hardox 450/500 base structure, AR400 tines) to optimize penetration, material retention, and structural integrity during demanding tasks such as:
Mining: Efficient clearing of loose overburden, coal, and fragmented ore; stockpile reclamation.
Logistics: Rapid sorting, grading, and cleanup of bulk materials (aggregate, biomass, recyclables) in port yards and depots.
Construction:* Precision grading of rough terrain, topsoil separation, and demolition debris management.

Field data demonstrates a 22-35% reduction in cycle times for material sorting and stockpile management compared to conventional buckets, directly translating to lower fuel consumption per ton moved and increased daily operational throughput. The attachment’s modular design ensures compatibility with major OEM excavators distributed by SEA LION International (XCMG, SINOTRUK, SHACMAN), minimizing integration complexity for fleet managers.

Regional Market Preference Drivers

The XR Series achieves dominant market preference across Africa, Russia, and Southeast Asia due to its targeted engineering solutions for region-specific operational challenges, validated through 18+ years of SEA LION’s field deployment and refurbishment expertise. Key differentiators include:

Region	Primary Operational Challenge	XR Series Adaptation	Measured Impact (Field Data)
Africa	Extreme abrasion (laterite, silica), limited maintenance infrastructure, cost sensitivity	Optimized tine spacing for high-volume loose material; simplified grease points; field-serviceable wear plates	+40% service life vs. standard rakes; 30% lower TCO due to reduced downtime & part replacement
Russia	Sub-zero operation (-40°C), frozen material handling, high impact loads	Cryo-treated steel alloys; reinforced hinge points; cold-flow hydraulic seals	Zero structural failures at -35°C; 25% faster thawing cycles due to efficient material fracturing
Southeast Asia	High humidity/corrosion, mixed material types (clay/rock), dense worksites	Marine-grade corrosion protection; adjustable tine density; compact profile for confined spaces	50% reduction in corrosion-related downtime; 18% higher productivity in mixed-soil grading

SEA LION International Value Integration

As an authorized distributor for SINOTRUK, SHACMAN, and XCMG with deep refurbishment capabilities, SEA LION ensures the XR Series delivers sustained value:
1. System Compatibility: Direct integration with excavators in our core distribution portfolio, eliminating hydraulic or control interface issues.
2. Longevity Assurance: XR Series components utilize the same wear-resistant materials and manufacturing standards as our refurbished truck undercarriages, validated for 8,000+ operational hours in harsh conditions.
3. Supply Chain Resilience: Global logistics network (RO-RO/Container) guarantees <30-day delivery of attachments and genuine spare parts (tines, pins, bushings) to key regional hubs, minimizing fleet stand-down time.
4. Transparency: Full traceability of material certifications (EN 10204 3.1) and wear-life analytics provided with each unit, supporting accurate maintenance planning.

Conclusion

For fleet managers and construction enterprises operating in Africa, Russia, or Southeast Asia, the SEA LION XR Series rake attachment is not merely a tool upgrade—it is a proven operational multiplier. Its region-specific engineering, seamless compatibility with prevalent equipment platforms, and SEA LION’s commitment to quality assurance and parts availability deliver quantifiable reductions in total cost of ownership (TCO) and tangible increases in site productivity. This specification represents the culmination of 18 years of industrial application data, designed explicitly for the reliability and efficiency demands of modern resource extraction, logistics, and infrastructure development. Partnering with SEA LION ensures access to attachments engineered for longevity, backed by a transparent supply chain and technical support infrastructure.

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Product: Excavator Rake Attachment System – Integrated Carrier Configuration

---

Technical Specifications: Excavator Rake Attachment Carrier Unit

The following specifications apply to the integrated excavator rake attachment system mounted on a heavy-duty carrier platform designed for high-efficiency material handling in demolition, land clearing, and site preparation operations. This configuration is optimized for durability, fuel economy, and maximum load throughput in industrial environments.

Parameter	Specification
Engine Model	Weichai WD615.62G3 (Euro III Compliant)
Rated Power	290 hp @ 2,200 rpm
Max Torque	1,250 N·m @ 1,400–1,600 rpm
Transmission	HW19710 10-speed Synchromesh Manual (HW Group)
Gear Ratios	1st: 12.85, 10th: 1.00, Reverse: 12.47
Axle Configuration	Front: 6.5-ton capacity; Rear Tandem: 11-ton per axle (22-ton total)
Total Axle Load	28.5 metric tons (GVWR)
Tire Specifications	12.00R20, 18PR, Radial, Tubeless, All-Steel Construction, Load Index: 152/148
Tire Application	Off-Highway, Cut-Resistant Tread (L-5 Pattern), Dual Rear Setup
Fuel Tank Capacity	340 liters (90 US gal)
Operating Weight	26,800 kg (with rake attachment and standard counterweight)
Rake Type	5-Tine Hydraulic Adjustable Rake (Grade 80 Steel Tines)
Rake Width	2.4 meters (94.5 in)
Hydraulic Flow	180–220 L/min, Operating Pressure: 24 MPa (3,500 psi)
Digging Force	185 kN (41,600 lbf)

---

Fuel Efficiency Analysis

The Weichai WD615 engine is calibrated for optimal combustion efficiency under variable load cycles typical in excavation and grading operations. When paired with the HW19710 transmission’s wide gear spread, the system maintains engine operation within the peak torque band during rake dragging and material displacement, reducing fuel waste.

• Average Fuel Consumption:
• Light Load (raking loose debris): 18–21 L/h
• Medium Load (brush/rock sorting): 24–27 L/h
• Heavy Load (compacted soil/root systems): 30–33 L/h

Fuel efficiency is further enhanced through:
– Engine Auto-Idle Function: Reduces rpm after 5 seconds of inactivity.
– Load-Sensing Hydraulics: Minimizes parasitic power loss.
– Thermal Management System: Maintains optimal coolant and oil temps, improving combustion consistency.

Over a 1,000-hour operating cycle, this configuration demonstrates a 9–12% improvement in fuel economy compared to legacy Tier II platforms with similar output.

---

Load Capacity & Operational Performance

The carrier unit is engineered to handle high-inertia forces generated during aggressive raking and pile manipulation. Key load performance metrics:

• Maximum Raking Pull Force: 168 kN (37,800 lbf) at drawbar
• Payload Capacity (Material Carry Mode): 5.2 metric tons (on flat terrain, low center of gravity)
• Slope Operation Limit: Up to 30% grade with full load (equipped with traction control)

The 12.00R20 tires provide:
– High load-bearing capability (152 = 3,750 kg per tire)
– Deep tread for off-road traction
– Resistance to puncture and sidewall damage in rocky or debris-filled environments

The HW19710 transmission ensures smooth power delivery across all gears, enabling controlled starts under load and reducing driveline shock. Axle load distribution is optimized to prevent overloading on soft ground, maintaining ground pressure below 0.75 MPa.

---

Conclusion

The excavator rake attachment system with Weichai WD615 engine and HW19710 transmission delivers industrial-grade reliability, superior load handling, and measurable fuel savings. Designed for high-uptime operations, this configuration meets the demands of large-scale site preparation and material management for construction fleets.

Quality Control & Inspection Standards

SEA LION INTERNATIONAL

INDUSTRIAL SPECIFICATION REPORT 2026
Document ID: SLIR-EXR-2026-01
Effective Date: 01 January 2026
Classification: For Fleet Managers & Construction Equipment Procurement

---

1. PRODUCT: EXCAVATOR RAKE ATTACHMENT (MODEL SERIES: EXR-2000)

Purpose: Heavy-duty material handling, grading, and trenching in extreme construction environments.

---

2. MANUFACTURING QUALITY SPECIFICATIONS

2.1 Chassis & Structural Integrity (Rough Terrain Focus)

The EXR-2000 chassis is engineered for sustained operation on unstable, high-impact terrain. Critical manufacturing processes ensure structural resilience:

Parameter	Specification	Validation Method	Compliance Standard
Base Material	ASTM A514-T1 Boron-Alloy Steel (1100 MPa Yield)	Mill Certificates + Third-Party Tensile Test	ISO 13031:2014 Sec. 5.2
Critical Joint Welding	Full-Penetration MIG (ER100S-G) w/ 100% UT	Ultrasonic Testing (ASME Sec V)	AWS D1.1 Class B
Impact Resistance (Charpy)	≥47 J @ -30°C (Avg. of 3 tests)	ASTM E23 Impact Testing	EN 10045-1
FEA Load Simulation	2.5x Rated Capacity @ 45° Impact Angle	ANSYS Mechanical v2025 (Non-Linear)	SEA LION SL-ENG-008
Hardness Profile	45-52 HRC (Cutting Edges), 28-32 HRC (Chassis)	Rockwell C Scale Testing	ISO 6508-1

Design Rationale: Multi-ribbed cross-section geometry distributes point loads across 7 primary load paths. Reinforced pivot housings utilize forged alloy inserts to prevent galling under torsional stress. All structural welds undergo post-weld heat treatment (PWHT) to relieve residual stresses.

2.2 Engine & Hydraulic Interface Durability

Note: Engine durability refers to compatibility with host excavator power systems.

Parameter	Specification	Validation Method
Hydraulic Flow Range	80-220 L/min (Optimized for 15-45 ton class)	Flow Bench Testing @ 350 bar
Pressure Surge Tolerance	420 bar (Peak, 500 ms duration)	Dynamic Pressure Cycling (10,000 cycles)
Thermal Management	≤85°C Fluid Temp Rise @ Continuous Duty	ISO 4413 Thermal Cycle Test
Host Engine Load Impact	<3% RPM Drop @ Max Flow (vs. Std. Bucket)	Dynamometer Testing (Tier 4 Final Engines)

Key Manufacturing Controls:
– Precision-machined hydraulic ports with 0.02mm concentricity tolerance to prevent seal extrusion.
– All rotating components balanced to ISO 1940-1 Grade G2.5 to minimize parasitic vibration.
– Corrosion protection: Zinc-Nickel plating (25µm min) + marine-grade polymer topcoat (ASTM B117 1000h salt spray).

---

3. PRE-DELIVERY INSPECTION (PDI) PROTOCOL

All EXR-2000 units undergo mandatory PDI per SEA LION PDI-EXR-2026 procedure before shipment. Critical checkpoints for fleet reliability:

3.1 Structural Verification

Checkpoint	Acceptance Criteria	Tool/Method
Chassis Dimensional Check	Max. deviation: ±1.5mm (vs. CAD model)	CMM Laser Scanning (FARO Arm)
Weld Integrity	Zero cracks/pores in Category 1 welds	Dye Penetrant (ASTM E1417) + UT Scan
Pivot Pin Clearance	0.05-0.12mm (Measured at 360° rotation)	Dial Indicator + Micrometer
Impact Zone Hardness	Within 5 HRC of target zone specification	Portable Hardness Tester (Proceq)

3.2 Functional & Durability Validation

Checkpoint	Test Procedure	Pass/Fail Threshold
Hydraulic Endurance	500 cycles @ 320 bar, 45°C fluid temp	Zero leaks; <2% flow loss
Structural Fatigue	10,000 cycles @ 1.8x rated load (ISO 10218)	No cracks; max. deflection 3mm
Rough Terrain Simulation	8-hour operation on calibrated test track	Bolt torque retention ≥95%
Cold Start Performance	-25°C soak → Immediate operation test	Full function within 60 seconds

---

4. QUALITY ASSURANCE COMMITMENT

• Traceability: Each unit serialized with QR-linked build record (materials, weld logs, test data).
• Warranty: 3-year structural coverage; 18 months hydraulic components (excludes wear items).
• Compliance: Exceeds ISO 13031:2014 (Earth-moving machinery – Attachments) and ISO 20474-1:2022 safety requirements.

SEA LION International maintains ISO 9001:2015 and ISO 14001:2015 certified manufacturing facilities. All EXR-2000 production occurs in controlled environments with real-time SPC monitoring of critical dimensions.

---

END OF REPORT
SEA LION International reserves the right to update specifications without notice to comply with evolving safety and performance standards.

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared for: Fleet Managers & Construction Companies
Subject: Logistics Solutions for Exporting Excavator Rake Attachments from China
Document ID: ISR-LOG-2026-04
Issuing Authority: SEA LION International – Global Equipment Logistics Division

---

Executive Summary

This report evaluates three primary maritime transport methods—RO-RO (Roll-on/Roll-off), Bulk Cargo, and Flat Rack container shipping—for the export of excavator rake attachments from manufacturing hubs in China (e.g., Qingdao, Shanghai, Ningbo) to global project sites. The analysis focuses on cost efficiency, equipment integrity, transit time, handling requirements, and corrosion protection protocols. A standardized wax-based anti-corrosion treatment is specified to mitigate seawater exposure during ocean transit.

---

Product Profile: Excavator Rake Attachment

Parameter	Specification
Weight Range	800 – 2,200 kg
Dimensions (L×W×H)	2.1 m × 1.4 m × 0.9 m (avg.)
Material	High-tensile steel (Q345B / S355JR)
Surface Finish	Sandblasted, primed
Corrosion Risk	High (due to saltwater exposure in transit)
Handling Requirement	Forklift or crane access required

---

Transport Method Comparison

Criteria	RO-RO Shipping	Bulk Cargo Shipping	Flat Rack Container
Loading Mechanism	Self-propelled or towed on/off vessel	Loosely stowed in hold via crane	Secured on open-frame container
Cargo Protection	Moderate (exposed decks)	Low (direct hold exposure)	High (strapping + weather cover)
Transit Time (China → EU/MEA)	28–35 days	30–40 days	32–38 days
Port Infrastructure	Requires RO-RO terminal	Standard bulk terminal	Standard container terminal
Handling Damage Risk	Medium (vehicle movement)	High (shifting in hold)	Low (secured load)
Cost per Unit (USD)	$950 – $1,300	$700 – $900	$1,400 – $1,800
Insurance Complexity	Moderate	High	Low to Moderate
Best For	High-volume, frequent shipments	Low-cost, non-urgent	High-value, corrosion-sensitive units

---

Corrosion Protection Protocol: Wax Spraying System

To ensure integrity during marine transit, all excavator rake attachments must undergo a standardized anti-corrosion treatment prior to shipment:

Wax-Based Protection Specifications

Parameter	Requirement
Coating Type	Solvent-based anti-corrosion wax spray
Application Method	Pressurized spray (even coat, 50–70 µm)
Coverage Areas	All exposed steel surfaces, pivot joints, bolt threads
Drying Time	2 hours at 25°C (ambient)
Salt Spray Resistance	Minimum 500 hrs (ASTM B117 test)
Removal Method	Biodegradable degreaser + high-pressure wash
Certification	ISO 12944-6:2018 compliant

Note: Wax application must occur within 24 hours of final surface preparation and prior to crating or loading. Re-inspection required if delay exceeds 72 hours.

---

Recommendations by Use Case

Scenario	Recommended Method	Rationale
High-volume export to EU	RO-RO	Faster turnaround, lower handling cost per unit, compatible with port infrastructure
Budget-sensitive project in Africa	Bulk Cargo	Lowest freight cost; acceptable if wax protection and desiccant use are enforced
High-value rake for offshore project	Flat Rack	Maximum protection, secure lashings, ease of customs inspection
Mixed equipment shipment (rakes + tools)	Flat Rack	Modular loading; compatibility with containerized logistics chain

---

Risk Mitigation Guidelines

• RO-RO: Ensure non-operational status; battery disconnected; secure all moving parts.
• Bulk Cargo: Mandate wooden skid base and corner protectors; use VCI (Vapor Corrosion Inhibitor) sachets inside sealed joints.
• Flat Rack: Lashing with ≥4 tensioned straps (2” width, 5,000 kg SWL); tarpaulin cover with UV resistance (280 g/m² min).

---

Conclusion

For excavator rake attachments exported from China, Flat Rack shipping offers the highest level of protection and is recommended for high-value or corrosion-sensitive deployments. RO-RO is optimal for volume efficiency and faster deployment cycles. Bulk Cargo remains a cost-effective option only when paired with rigorous anti-corrosion protocols, including mandatory wax spraying.

All shipments must integrate the specified wax-based corrosion protection system to ensure equipment readiness upon arrival. SEA LION International enforces compliance with ISO 9001 and IACS standards across all transport modes.

---

End of Report
SEA LION International – Engineering Excellence in Global Equipment Deployment
