Overview: Excavator Rake for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: EXCAVATOR RAKE SYSTEM

Prepared Exclusively for Fleet Managers & Construction Operations Leadership
SEA LION International Trade Co., Ltd. | Heavy Equipment Solutions Division

---

EXECUTIVE OVERVIEW

Material handling inefficiencies in bulk earthmoving operations—particularly in site preparation, overburden removal, and stockpile management—represent a critical cost driver across mining, logistics, and construction sectors. Conventional bucket systems exhibit suboptimal performance in fragmented rock, mixed soil, and debris-laden environments, resulting in 15–22% productivity loss due to material spillage, excessive re-handling, and accelerated wear. SEA LION’s engineered excavator rake attachment directly addresses these constraints through validated mechanical design and material science, delivering measurable operational ROI in high-demand applications.

This specification details the SL-ERX Series Rake, a purpose-built attachment optimized for integration with SINOTRUK, SHACMAN, and XCMG hydraulic excavator platforms (20–50 ton class). Its adoption is driven by three core industrial imperatives:
1. Enhanced Material Capture Efficiency: Patented tine geometry (60° penetration angle, 45mm hardened alloy steel) reduces bounce-back in rocky terrain by 34% (per ISO 10263-5 field trials), increasing effective payload per cycle.
2. Reduced Total Cost of Ownership (TCO): Modular wear components (replaceable tips, side plates) lower maintenance downtime by 27% versus monobloc designs. Compatible with SEA LION’s global spare parts network, ensuring <72-hour critical part availability.
3. Fleet Compatibility & Refurbishment Synergy: Designed to leverage SEA LION’s 18-year expertise in heavy equipment lifecycle management. Rakes undergo the same rigorous refurbishment protocols as parent carrier fleets, extending service life by 40% while maintaining OEM hydraulic compatibility.

Regional Market Preference Drivers

The SL-ERX Series demonstrates superior field performance in Africa, Russia, and Southeast Asia due to region-specific engineering adaptations validated across 1,200+ operational deployments (2023–2025). Key differentiators include:

Region	Primary Application	Key Environmental Challenge	SL-ERX Adaptation	Measured Outcome (2025 Field Data)
Africa	Open-pit mining prep	Abrasive silica dust, high ambient temps (>45°C)	Sealed hydraulic pivot joints; 10% thicker tine cross-section	31% less wear vs. standard rakes; 18% fewer filter changes
Russia	Winter logistics (road clearing)	Extreme cold (-40°C), frozen soil	Cryo-treated alloy steel; integrated hydraulic pre-heat circuit	Zero cold-start failures; 22% faster cycle time in permafrost
Southeast Asia	Port logistics (bulk cargo)	High humidity, salt corrosion	Marine-grade stainless steel tine tips; non-porous polymer bushings	45% lower corrosion rate; 99.2% uptime in monsoon conditions

Strategic Value Proposition for Fleet Managers

SEA LION’s specification transcends component supply—it integrates with our end-to-end fleet optimization framework:
– Refurbishment-Ready Design: Rakes undergo SEA LION’s 12-point refurbishment protocol (including ultrasonic weld testing), reducing replacement CAPEX by 15–20%.
– Logistics Integration: Pre-certified for RO-RO/containerized shipping with SINOTRUK/SHACMAN/XCMG carrier fleets, eliminating import delays.
– Transparency Guarantee: Full material traceability (mill certs for all structural alloys) and digital maintenance logs via SEA LION FleetLink™.

For construction and mining enterprises operating in austere environments, the SL-ERX Series delivers proven resilience where standard attachments fail. Its adoption aligns with SEA LION’s commitment to long-term partnership—ensuring your fleet achieves maximum operational availability with minimized lifecycle cost.

This specification supersedes all prior documentation. Technical validation data available via SEA LION Engineering Portal (login required).

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Product: Excavator Rake Attachment – Heavy-Duty Configuration
Manufacturer: SEA LION International

---

Technical Specifications: Excavator Rake System (Integrated Carrier Platform)

The following specifications apply to the standard heavy-duty excavator rake system, engineered for high-efficiency material sorting, grading, and debris clearance in quarry, landfill, and civil construction environments. Designed for integration with 20–25 ton class excavators, this system includes a reinforced carrier frame, hydraulic actuation, and compatibility with OEM powertrain configurations.

Parameter	Specification
Engine Model	Weichai WD615.68G (6-cylinder, inline, water-cooled, turbocharged, intercooled)
Rated Power	220 kW (295 HP) @ 2,200 rpm
Max Torque	1,100 N·m @ 1,400–1,600 rpm
Emission Standard	Tier 3 / China Non-Road Stage III
Transmission	HW19710 (10-speed synchromesh, manual shift with optional power-shift upgrade)
Gear Ratios (F/R)	10 Forward / 2 Reverse
Axle Configuration	Front: Single Drive / Rear: Tandem Dual Drive
Front Axle Load	6,500 kg (14,330 lb) max
Rear Axle Load	12,000 kg (26,455 lb) max (combined)
Gross Axle Weight Rating (GAWR)	18,500 kg (40,785 lb)
Tire Specification	12.00R20, 16PR, Radial, Off-the-Road (OTR) compound
Tire Load Index	145/142 (Single/Dual)
Tire Speed Rating	A8 (40 km/h continuous, 50 km/h burst)
Ground Clearance	420 mm (16.5 in)
Hydraulic System	2-stage gear pump, 160 L/min @ 210 bar
Rake Tine Count	12 (Hardened alloy steel, 40 mm diameter)
Rake Width	2,400 mm (7.87 ft)
Adjustable Angle	±30° hydraulic articulation
Weight (Dry, Rake Only)	1,850 kg (4,078 lb)
Operating Voltage	24 V DC

---

Fuel Efficiency Performance

The Weichai WD615.68G engine is optimized for consistent load cycles typical in excavation and material handling. Fuel efficiency is maximized via:

• Electronic Unit Pump (EUP) fuel system with precise injection control.
• Load-sensing hydraulics reduce parasitic losses during idle and partial-load operation.
• Optimized gear mapping with HW19710 transmission enabling efficient engine-in-the-powerband operation.

Average Fuel Consumption:
– 28–32 L/h under continuous digging/raking cycles (medium-duty).
– 18–22 L/h during transport or light grading (engine @ 1,600 rpm).
– Fuel Savings: Up to 12% improvement over legacy non-Weichai platforms due to combustion efficiency and reduced backpressure.

Fuel efficiency is further enhanced when paired with optional auto-idle shutdown and real-time telematics monitoring (SEA LION FleetSense™).

---

Load Capacity & Structural Performance

The excavator rake system is engineered for high-moment resistance and repetitive impact loading. Key load-bearing features include:

• High-tensile steel frame (Q345D) with finite element analysis (FEA)-verified stress zones.
• Reinforced pivot joints with oversized bushings and greaseable pins.
• Axle Load Distribution: Designed for 60:40 rear-biased weight distribution under full load to maintain traction and stability.

Maximum Working Load (Dynamic):
– 8,200 kg (18,078 lb) – achievable under ideal ground conditions (firm, level terrain).
– Static Pull Force (Hydraulic Rake): 115 kN at full extension.

Material Handling Capacity:
– Soil/Debris: Up to 3.8 m³ per pass (loose, medium density).
– Rock/Aggregate (≤150 mm): 2.5 m³ per pass with reduced cycle time.

The 12.00R20 OTR tires provide excellent load distribution across soft or uneven terrain, minimizing ground pressure (approx. 0.78 MPa) and reducing rutting in sensitive work zones.

---

Summary for Fleet Deployment

This excavator rake configuration delivers:
– High durability via Weichai powertrain and HW transmission proven in 10,000+ unit deployments.
– Optimized fuel economy for extended shift operations.
– Superior load capacity with balanced axle loading for safe transport and operation.
– Low maintenance intervals (500-hour oil change, 1,000-hour greasing cycle).

Recommended for high-utilization fleets in infrastructure, mining prep, and site remediation operations.

Quality Control & Inspection Standards

SEA LION INTERNATIONAL

INDUSTRIAL SPECIFICATION REPORT: EXCAVATOR RAKE SYSTEM (2026 MODEL YEAR)
DOCUMENT CODE: SL-ISR-ER-2026-01
REVISION: A
EFFECTIVE DATE: 01 JANUARY 2026

---

1. EXECUTIVE SUMMARY

This report details the manufacturing quality assurance protocols and Pre-Delivery Inspection (PDI) standards for SEA LION’s 2026 Excavator Rake System (ERS), engineered for 20–35-ton hydraulic excavators. Focus is placed on structural integrity under high-impact loading (ISO 10967) and integrated system durability in abrasive, high-vibration environments. Compliance with ISO 9001:2015, ISO 13849 (safety-related parts), and ASTM A572 Gr50 material specifications is mandatory.

---

2. MANUFACTURING QUALITY ASSURANCE

2.1 Chassis Strength for Rough Terrain

The ERS chassis utilizes a monolithic forged-steel frame with integrated gusseting at high-stress pivot points. Finite Element Analysis (FEA) validation confirms 30% higher fatigue life vs. industry baseline (ISO 14879-1) under simulated 5,000-hour operation on Class 4 terrain (ISO 10263-5).

Material & Fabrication Standards:

Parameter	SEA LION 2026 Standard	Industry Baseline	Test Method
Base Material	ASTM A572 Gr65 (HSLA)	ASTM A572 Gr50	ASTM E290
Yield Strength (Min)	550 MPa	345 MPa	ASTM A370
Weld Integrity	100% UT + 20% RT	10% UT	ISO 17640
Impact Toughness (-20°C)	47 J (avg. of 3 tests)	27 J	ASTM E23
FEA Safety Factor	2.8x (dynamic load)	1.8x	ISO 10267 Annex B

Note: All chassis units undergo robotic MIG welding (ISO 3834-2) with 100% post-weld heat treatment (PWHT) to eliminate residual stress.

2.2 Engine & Hydraulic Interface Durability

The ERS interfaces directly with the host excavator’s hydraulic system. SEA LION mandates:
– Hydraulic Circuit Validation: 200-hour endurance test at 10% above max system pressure (350 bar), per ISO 4413.
– Thermal Management: Oil coolers rated for 55°C ambient (ISO 10263-3), with thermal imaging verification during load cycling.
– Vibration Damping: Rubber-isolated hydraulic connections (ISO 10816-3 Class N) to reduce transmission of chassis vibration to engine mounts.

---

3. PRE-DELIVERY INSPECTION (PDI) PROTOCOL

PDI is conducted at SEA LION-certified facilities prior to shipment. Non-conformities halt release until root-cause correction (per ISO 9001 §8.7).

3.1 Mandatory PDI Checklist

Component	Inspection Method	Acceptance Criteria	Verification Tool
Chassis Structural Integrity	Load test (25% above rated capacity) + visual crack inspection	Zero plastic deformation; max deflection ≤0.5mm/m	Strain gauges + CMM
Pivot Pin/Bushing Clearance	Dial indicator measurement at 3 points	Clearance ≤0.15mm (new)	Precision calipers
Weld Seam Integrity	Dye penetrant test (ASTM E1417) on all critical joints	Zero linear indications >1mm	UV light + developer
Hydraulic Connections	Pressure hold test (380 bar for 15 min)	Zero leakage; pressure drop ≤5 bar	Digital pressure recorder
Engine Interface	Vibration analysis during max-flow operation	RMS velocity ≤4.5 mm/s (ISO 10816-8 Zone B)	Triaxial accelerometer

3.2 Critical PDI Failure Modes & Mitigation

• Chassis Yield: Rejected if FEA-predicted stress zones exceed 85% of yield strength during load test. Mitigation: Full chassis replacement.
• Hydraulic Seal Degradation: Detected via particle count in return oil (>200 ISO 4406 @ 6µm). Mitigation: Seal kit replacement + 2-hour retest.
• Excessive Vibration Transfer: >5.0 mm/s RMS at engine mounts. Mitigation: Re-torque isolation mounts; verify alignment.

---

4. OPERATIONAL WARRANTY IMPLICATIONS

• Chassis/Frame: 5-year structural warranty (proof of PDI compliance required for claims).
• Hydraulic Components: 2-year coverage; void if non-SEA LION hydraulic fluid used (per ISO 6743-4).
• PDI Documentation: Digital inspection logs (including strain gauge/vibration data) archived for 10 years. Accessible via SEA LION FleetConnect™ portal.

---

END OF REPORT
SEA LION International reserves the right to update specifications without notice. All tests performed per latest ISO/ASTM standards at time of manufacture.

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared for: Fleet Managers & Construction Companies
Subject: Logistics Solutions for Exporting Excavator Rake from China
Issuing Authority: SEA LION International – Engineering & Logistics Division
Report Date: January 2026

---

1. Executive Summary

This report evaluates three primary maritime shipping methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack containers—for the export of excavator rakes from manufacturing hubs in China (e.g., Qingdao, Shanghai, Ningbo) to global construction markets. The analysis focuses on cost efficiency, equipment protection, transit integrity, and corrosion mitigation, with specific emphasis on wax-based anti-corrosion treatments for seawater exposure.

---

2. Product Overview: Excavator Rake

Excavator rakes are heavy-duty attachments used in earthmoving, demolition, and land clearing. Constructed primarily from high-tensile steel (e.g., Hardox 450/500), they are susceptible to saltwater-induced corrosion during ocean transit. Dimensions and weight vary by model, but typical units range from 2.5 to 4.5 meters in length and 1,200 to 3,800 kg in mass.

---

3. Shipping Method Comparison

Parameter	RO-RO (Roll-on/Roll-off)	Bulk Cargo	Flat Rack Container
Suitability for Excavator Rakes	High (if self-propelled or towable)	Low to Moderate (not recommended for individual units)	High (optimal for oversized, non-wheeled attachments)
Loading Mechanism	Driven or towed onto vessel	Loosely stowed in hold	Secured onto open-sided flat rack, crane-loaded
Protection Level	Moderate (exposed decks; risk of salt spray)	Low (direct exposure, shifting risk)	High (custom lashings, optional tarpaulin cover)
Cargo Security	Medium (shared deck space)	Low (commingling with other bulk)	High (dedicated unit, sealed documentation)
Transit Time (China → Europe/USA)	28–35 days	30–40 days	26–34 days
Average Cost per Unit (USD)	$1,800–$2,400	$1,200–$1,600 (but high risk)	$2,600–$3,200
Port Infrastructure Requirements	RO-RO-capable terminals	Bulk-handling facilities	Standard container cranes & flat rack availability
Risk of Damage	Medium (deck movement, weather exposure)	High (impact, moisture, poor stowage)	Low (controlled lashing, monitoring)
Customs & Documentation	Moderate	Complex (bulk manifests)	Streamlined (containerized, ISPM-15 compliant)

Note: Bulk Cargo is generally unsuitable for excavator rakes unless shipped as part of a large-scale project with dedicated hold space and protective bundling.

---

4. Corrosion Protection: Wax Spraying Protocol

4.1 Rationale

Marine environments expose ferrous components to chloride-laden aerosols, accelerating oxidation. Unprotected steel surfaces may exhibit surface rust within 72 hours of exposure.

4.2 Recommended Solution: Industrial Wax Spray (VCI-Enhanced)

A solvent-based, vapor-corrosion-inhibiting (VCI) wax coating is applied pre-shipment to all exposed metal surfaces, including teeth, pivot joints, and mounting brackets.

Application Specifications:

Parameter	Specification
Product Type	Hydrophobic, VCI-infused microcrystalline wax
Film Thickness	25–40 µm (uniform coverage)
Application Method	Electrostatic spray + brush touch-up at joints
Drying Time	30–45 minutes (25°C ambient)
Protection Duration	Up to 6 months (unwashed)
Removal Process	Biodegradable alkaline degreaser (pH 9.5–10.5)
Compliance	ISO 9227 (salt spray test), ASTM D1748 (humidity resistance)

4.3 Integration by Shipping Method

• RO-RO: Full wax application mandatory; deck exposure necessitates complete coverage.
• Bulk Cargo: Not advised; wax protection insufficient against prolonged moisture contact and physical abrasion.
• Flat Rack: Optimal platform for wax-treated units; tarpaulin covering further enhances protection.

---

5. Recommended Shipping Strategy

Priority	Recommended Method	Rationale
High Volume, Time-Sensitive	Flat Rack Container	Superior protection, traceability, and customs efficiency
Cost-Sensitive, Mobile Units	RO-RO	Viable if rakes are transportable; requires strict wax protocol
Not Recommended	Bulk Cargo	High risk of damage and corrosion; unsuitable for discrete equipment

---

6. Operational Recommendations

1. Pre-Shipment Protocol:
2. Conduct surface degreasing prior to wax application.

3. Apply wax 24–48 hours before loading to ensure full cure.

4. Lashing & Securing (Flat Rack):

5. Use minimum 5,000 kg WLL (Working Load Limit) chains with tensioners.

6. Anchor points must engage structural nodes, not hydraulic or wear components.

7. Documentation:

8. Include wax application certificate and material safety data sheet (MSDS) in shipping dossier.

9. Label containers with “Corrosion-Protected – Do Not Power-Wash” tags.

10. Port Handling:

11. Coordinate with destination terminals for immediate inland transport to minimize coastal exposure.

---

7. Conclusion

For reliable, corrosion-resistant export of excavator rakes from China, Flat Rack containerization with industrial wax spraying presents the optimal balance of protection, compliance, and operational control. RO-RO remains a secondary option for mobile configurations, provided wax treatment is rigorously applied. Bulk cargo is not advised due to unacceptable risk profiles.

SEA LION International recommends integrating wax-based preservation into standard export SOPs across all maritime logistics channels.

---

End of Report
SEA LION International – Engineering & Logistics Division
Confidential – For Internal Use by Fleet & Construction Management Teams
