Overview: Excavator Red for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW

Model Designation: EXCAVATOR RED (XCMG Model Series: XE350G-RED)
Prepared For: Fleet Managers & Construction Operations Leadership
Issuing Authority: SEA LION International Trade Co., Ltd. | Heavy Equipment Division

---

1. PURPOSE & SCOPE

This report details the operational specifications and market-specific advantages of the XCMG XE350G-RED (“Excavator Red”), a 35-ton class hydraulic excavator engineered for high-stress environments. Focus is placed on validated performance in mining extraction, bulk material logistics, and large-scale earthmoving operations across Africa, Russia, and Southeast Asia. SEA LION International, as an authorized XCMG distributor and SINOTRUK/SHACMAN partner, provides this technical assessment based on 18+ years of field data from harsh-climate deployments.

---

2. CORE APPLICATIONS & OPERATIONAL ADVANTAGE

The XE350G-RED is optimized for duty cycles where reliability under load and reduced lifecycle cost are non-negotiable. Key differentiators include:

• Mining: Reinforced undercarriage (U-type track frame), 32% higher tensile strength bucket linkage, and dual-stage dust filtration for open-pit copper/iron ore operations (Africa).
• Logistics: High-volume loading capacity (3.2 m³ standard bucket) with 0.5° swing precision for rail/ship loading in port infrastructure (Southeast Asia).
• Construction: Cold-start capability to -40°C and hydraulic system insulation for deep foundation work in permafrost zones (Russia).

---

3. MARKET PREFERENCE ANALYSIS: AFRICA, RUSSIA, SOUTHEAST ASIA

Regional adoption is driven by proven resilience to environmental extremes and total cost of ownership (TCO) superiority against legacy European/Japanese platforms. SEA LION’s refurbishment program and parts logistics network directly address critical regional pain points:

Region	Primary Application	Key Environmental Challenge	XE350G-RED Advantage	SEA LION Value-Add
Africa	Open-Pit Mining	Abrasive dust, 45°C+ temps	Sealed cab (ISO 10218-1), 1,000-hour dust filter service interval	On-site refurbishment hubs (Johannesburg, Dar es Salaam); 72-hr critical parts dispatch
Russia	Infrastructure	-40°C to -50°C, permafrost	Engine pre-heater (-45°C start), hydraulic oil viscosity control (-55°C operable)	Winterization kits pre-installed; RO-RO shipments to Murmansk/St. Petersburg
Southeast Asia	Port Logistics	95% humidity, monsoon rains	Marine-grade corrosion protection (ISO 12944 C5-M), sealed electrical connectors	Containerized shipping; humidity-controlled parts storage (Singapore hub)

---

4. WHY THIS MODEL DOMINATES TARGET MARKETS

• TCO Reduction: 22% lower maintenance costs vs. Tier 1 competitors (verified by SEA LION field data, 2023-2025), achieved through simplified hydraulic schematics and locally serviceable components.
• Duty Cycle Resilience: 15,000-hour major overhaul interval (vs. industry avg. 12,000 hrs) under continuous 10-hr/day mining operations.
• Parts Ecosystem: SEA LION’s global logistics network ensures <14-day delivery of OEM-grade spare parts across all target regions, eliminating project delays.
• Refurbishment Standard: SEA LION-certified rebuilt units undergo 200+ point inspection (ISO 9001:2015), matching 85% of new-unit performance at 60% capital cost.

---

5. CONCLUSION

The XCMG XE350G-RED is not merely an excavator—it is a ruggedized productivity platform engineered for the operational realities of Africa, Russia, and Southeast Asia. Its dominance in these markets stems from quantifiable durability in extreme conditions, demonstrable TCO leadership, and seamless integration with SEA LION’s industrial-grade support infrastructure. For fleet managers prioritizing uptime in mining, logistics, or construction, this model represents the optimal balance of capital efficiency and field-proven resilience. SEA LION International stands ready to deploy this asset with technical precision and long-term partnership commitment.

---

Report Validity: Data reflects verified field performance as of Q1 2026. Specifications subject to XCMG engineering updates. SEA LION International maintains exclusive distribution rights for XCMG heavy equipment in 47 emerging markets.

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Model Designation: Excavator RED
Manufacturer: SEA LION International

---

Technical Specifications – Excavator RED

Parameter	Specification
Model Designation	Excavator RED
Engine Model	WD615 (Weichai Power)
Engine Type	6-Cylinder, Inline, Water-Cooled, Turbocharged Diesel
Horsepower (HP)	220 HP @ 2,200 RPM
Transmission System	HW19710 – 10-Speed Manual Synchromesh
Transmission Layout	Dual-Range, High/Low Gears, Reverse Synchronized
Axle Load (Front/Rear)	8,500 kg / 11,500 kg (Total: 20,000 kg)
Tire Specification	12.00R20 Radial, Load Range G, Tubeless
Tire Load Index	145/142 (Front/Rear) – 3,650 kg per tire max
Operating Weight	19,800 kg (standard configuration)
Bucket Capacity	1.2 m³ (standard bucket)
Digging Depth	6,800 mm
Swing Speed	10.5 RPM
Travel Speed	0–38 km/h (two-speed, transmission-controlled)

---

Fuel Efficiency Analysis

The Excavator RED, powered by the Weichai WD615 diesel engine, is engineered for optimal fuel economy in heavy-cycle operations. Under ISO 9249 standard testing conditions:

• Average Fuel Consumption: 28–32 L/h during mixed operation (digging, swinging, loading)
• Eco-Mode Optimization: Reduces fuel use by up to 15% during light-load cycles without sacrificing torque delivery
• High-Pressure Common Rail (HPCR) Injection: Enhances combustion efficiency and reduces particulate emissions
• Thermal Management System: Regulates engine temperature to maintain peak efficiency in ambient ranges from -20°C to +50°C

Field data from 2025 pilot deployments across quarry and urban infrastructure projects indicate 12–18% improved fuel economy compared to legacy models using equivalent displacement engines.

---

Load Capacity & Structural Performance

The axle and frame design of the Excavator RED supports demanding load profiles typical in earthmoving and demolition applications.

• Maximum Payload Tolerance: 20,000 kg (GVW) distributed across reinforced front and rear axles
• Front Axle Load: 8,500 kg – Equipped with double-tapered roller bearings and hydraulic dampening
• Rear Axle Load: 11,500 kg – Integrated differential lock and torque biasing for traction control
• Frame Material: High-tensile steel (Yield Strength: 460 MPa), stress-tested for 10,000+ hour service life

The 12.00R20 radial tires provide:
– Superior cut and abrasion resistance for off-road terrains
– Low rolling resistance, contributing to fuel savings
– Enhanced load stability on soft or uneven ground (rated for 3,650 kg per tire at 85 psi)

---

Operational Recommendations

• Transmission Use: Utilize HW19710’s dual-range gearing for gradeability control; low range recommended for inclines >15%
• Tire Maintenance: Monitor inflation pressure weekly; underinflation increases fuel consumption by up to 8% and reduces tire life
• Engine Service Interval: 500-hour oil and filter change cycle; Weichai WD615 compatible with ultra-low sulfur diesel (ULSD) and biodiesel blends up to B10

---

Conclusion: The Excavator RED delivers a balanced performance profile ideal for mid-to-heavy-duty construction fleets. Its Weichai WD615 engine, HW19710 transmission, and high-load 12.00R20 tire configuration ensure durability, fuel efficiency, and operational versatility across diverse job sites. Recommended for high-uptime deployment in infrastructure, mining, and municipal projects.

Quality Control & Inspection Standards

SEA LION INDUSTRIAL SPECIFICATION REPORT: EXCAVATOR RED (2026 MODEL YEAR)

Document ID: SL-ES-2026-RED-001
Effective Date: 01 January 2026
Prepared For: Fleet Operations Managers & Construction Equipment Procurement Teams

---

1. MANUFACTURING QUALITY OVERVIEW

The EXCAVATOR RED (ER-26) platform undergoes precision manufacturing per ISO 9001:2015 and ISO 13849-1 (PLd) standards. Critical focus areas for rough-terrain operation are chassis integrity and powertrain resilience.

1.1 Chassis & Undercarriage Construction

Monocoque frame design utilizing HARDOX 500 wear plate (500 HB) with robotic MIG welding (EN 1090 EXC 3 compliance).

Component	Material Spec	Process Control	Validation Test
Main Frame Rails	HARDOX 500 (12-25mm)	Laser-cut tolerances ±0.5mm; Post-weld stress relief	150% rated load cyclic test (50k cycles)
Track Rollers	Forged 42CrMo4	Induction hardening (52-58 HRC)	1,000 km abrasive terrain simulation
Boom/Pin Interface	ASTM A514 Gr. Q	Finite Element Analysis (FEA) at 3x max load	Dynamic shock load test (ISO 10218-1)

Key Outcome: 40% higher fatigue resistance vs. industry baseline (per ISO 14121-1 validation). Frame deflection < 2mm under 50,000 kgf point load.

1.2 Engine & Powertrain Durability

SEA LION SL-D13 Tier 5 Final engine with integrated thermal management system.

System	Specification	Durability Enhancement
Cylinder Block	Compacted Graphite Iron (CGI)	35% higher thermal fatigue resistance
Turbocharger	Dual-stage VGT (Variable Geometry)	Oil-cooled bearings; 15,000 hr TBO
Cooling System	Dual-circuit (engine/hydraulic)	25°C lower peak oil temp in 50°C ambient
Fuel System	2,500 bar common rail; 10µm filtration	Zero injector clogging in 500-hr dust test

Key Outcome: 20,000-hour mean time between failures (MTBF) under continuous heavy-load operation (SAE J1839).

---

2. PRE-DELIVERY INSPECTION (PDI) PROTOCOL

All ER-26 units undergo 18-point PDI per SEA LION Standard SL-TP-450. Critical checks for rough-terrain readiness:

2.1 Structural Integrity Verification

• Chassis Alignment: Laser measurement of frame geometry (tolerance: ±1.5mm over 6m length)
• Weld Integrity: 100% ultrasonic testing (UT) of primary structural welds (ASME BPVC Sec. V)
• Bolt Torque Validation: Critical fasteners (ISO 4762) re-torqued to 110% of spec; documented via digital torque wrench

2.2 Powertrain & Hydraulic System Validation

Test Sequence	Parameter	Acceptance Threshold	Tooling
Cold Start Cycle	Crank time (0°C)	≤ 4.5 sec	Engine analyzer SL-DA-7
Hydraulic Contamination	NAS 1638 Class	≤ NAS 8 (ISO 4406:2017)	Particle counter SL-PC-3
Load Test (100%)	Oil pressure stability	±5% over 30 min	Data logger SL-DL-9
Thermal Soak	Coolant temp rise	≤ 1.2°C/min at max load	IR thermography

2.3 Rough-Terrain Functional Test

• Procedure: 2-hour simulated operation on calibrated test course (25% slope, 150mm obstacles, 30° articulation)
• Pass/Fail Criteria:
• Zero frame cracks (dye penetrant inspection post-test)
• Hydraulic pressure fluctuation < 8% at 45 MPa
• Engine derating events ≤ 1 during test

---

3. OPERATIONAL READINESS CERTIFICATION

Upon PDI completion, ER-26 units receive:
– SEA LION Durability Certificate: Validating compliance with ISO 10218-2 (Earth-moving machinery safety)
– Component Life Tracking Chip: Embedded RFID logging engine hours, thermal cycles, and load profiles
– Fleet Integration Package: Pre-loaded telematics for predictive maintenance (vibration analysis + oil degradation monitoring)

Note: All ER-26 chassis undergo mandatory 200-hour break-in protocol at SEA LION proving grounds prior to customer delivery. Field data shows 32% reduction in early-life failures versus industry average.

---

END OF REPORT
SEA LION International – Engineering Excellence in Heavy Equipment
This document contains proprietary technical data. Unauthorized distribution prohibited.

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared by: SEA LION International – Marine & Heavy Equipment Logistics Division
Subject: Export Logistics Solutions for ‘Excavator Red’ from China
Target Audience: Fleet Managers, Construction Equipment Procurement Officers, and Logistics Coordinators

---

Executive Summary

This report evaluates three primary maritime transport methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack container shipping—for the export of heavy construction machinery, specifically units painted in “Excavator Red,” from manufacturing hubs in China (e.g., Xuzhou, Shenyang, Changsha) to global destinations. The analysis focuses on cost efficiency, equipment integrity, transit time, and corrosion protection, with specific emphasis on wax-based anti-corrosion treatments for seawater exposure.

---

1. Equipment Overview: ‘Excavator Red’ Units

“Excavator Red” refers to standardized hydraulic excavators (typically 20–40 ton class) produced by major Chinese OEMs (e.g., XCMG, SANY, Liugong), finished in high-visibility red epoxy-polyurethane coating. These units are exported in disassembled or operational states depending on shipment method.

Parameter	Specification
Weight Range	22,000 – 42,000 kg
Dimensions (L×W×H)	10.2 m × 3.2 m × 3.5 m (avg)
Operating State for Export	Cold-stored, fuel drained, batteries off
Corrosion Risk Exposure	High (due to salt-laden marine air)

---

2. Shipping Method Comparison

Criteria	RO-RO (Roll-on/Roll-off)	Bulk Cargo (Loose Loaded)	Flat Rack Container (20’/40′)
Loading Mechanism	Self-propelled or towed onto vessel	Craned/lifted into hold	Secured onto open-sided frame container
Suitability for Excavators	High (ideal for operational units)	Medium (requires disassembly)	High (for non-operational or tall units)
Protection from Elements	Moderate (exposed decks, partial cover)	Low (unprotected in hold)	High (with tarpaulin + wax protection)
Transit Time (China → EU/ME)	28–35 days	30–40 days	32–38 days
Average Cost per Unit (USD)	$4,200 – $5,800	$3,500 – $4,500	$6,000 – $7,500
Risk of Damage	Low (controlled roll-on/off)	High (handling in bulk)	Medium (secure lashing critical)
Port Infrastructure Need	RO-RO ramps required	Standard bulk terminal	Container crane + flat rack availability
Customs Clearance Speed	Fast (pre-inspected, unitized)	Slow (bulk inspection)	Fast (containerized, trackable)

---

3. Corrosion Protection: Wax Spraying Protocol

Seawater and high-humidity marine environments pose a significant risk to ferrous components during transit. To mitigate salt-induced corrosion, automated wax-based anti-corrosion spraying is recommended as a standard pre-shipment procedure.

3.1 Wax Spraying Specifications

Parameter	Specification
Coating Type	Solvent-based synthetic wax emulsion
Application Method	High-pressure spray (15–20 bar)
Coverage Areas	Undercarriage, boom joints, hydraulic rams, exposed fasteners
Film Thickness	50–75 µm (dry)
Salt Spray Resistance (ASTM B117)	>500 hours (no red rust)
Removal Process	Biodegradable citrus-based solvent or steam wash

3.2 Method-Specific Protection Efficacy

Shipping Method	Wax Efficacy	Notes
RO-RO	Moderate	Wax protects critical zones; exposed surfaces may require re-treatment post-transit
Bulk Cargo	Low–Moderate	High handling increases wax abrasion; full re-coating often needed
Flat Rack	High	Combined with waterproof tarp and desiccants, wax provides optimal protection

Recommendation: Wax spraying is mandatory for all export units. Flat Rack shipments with wax + tarpaulin offer the highest corrosion resistance.

---

4. Operational Recommendations

Factor	Recommended Solution
High-Volume Fleets	RO-RO (fast turnaround, lower handling risk)
Disassembled or Oversized Units	Flat Rack (flexible dimension handling)
Budget-Constrained Projects	Bulk Cargo (with wax + post-arrival refurbishment budget)
Corrosion-Sensitive Regions (e.g., GCC, SE Asia)	Flat Rack + wax + humidity-controlled desiccant packs

---

5. Conclusion

For the export of “Excavator Red” units from China, Flat Rack shipping with industrial wax corrosion protection provides the optimal balance of equipment safety and long-term integrity, particularly for corrosion-prone regions. RO-RO remains the most efficient for operational fleets with access to roll-on infrastructure. Bulk Cargo, while cost-effective, incurs higher post-arrival maintenance and should be used only when other methods are unavailable.

SEA LION International recommends integrating automated wax spraying into OEM pre-shipment protocols across all methods to ensure compliance with ISO 9227 (corrosion testing) and extend equipment service life.

---

End of Report – SEA LION International, 2026
Confidential – For Internal Logistics Planning Use Only
