Overview: Howo Dump Truck 64 for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026

SEA LION INTERNATIONAL TRADE CO., LTD.
Authorized Distributor: SINOTRUK | SHACMAN | XCMG | 18+ Years Global Heavy Truck Export Expertise

---

EXECUTIVE OVERVIEW: HOWO DUMP TRUCK 64 (HD-64)

Optimized for Mining, Construction & Bulk Logistics in Demanding Environments

The HOWO Dump Truck 64 (HD-64), manufactured by SINOTRUK and distributed globally by SEA LION International, represents a benchmark in heavy-duty off-highway transport for mining, large-scale construction, and bulk material logistics. Engineered for maximum payload efficiency (64-ton class) and operational resilience under extreme site conditions, the HD-64 delivers a demonstrable reduction in total cost of ownership (TCO) through its rugged powertrain, simplified maintenance architecture, and adaptability to region-specific fuel and terrain challenges. This model is not merely a transport solution but a productivity multiplier in environments where downtime equates to critical project delays.

Core Application Advantages

• Mining: Excels in overburden removal and ore haulage on unpaved, steep-grade mine roads. Reinforced chassis (U-shaped 320mm high-strength steel frame), 6×4/8×4 configurations, and aggressive tire options ensure stability on loose surfaces. Hydraulic retarder integration significantly reduces brake wear during sustained descents.
• Construction: Ideal for large earthmoving projects (dams, highways, urban infrastructure) requiring high-cycle dumping. Fast-cycle hoist system (≤18s dump time), reinforced tailgate latching, and optimized body geometry (18-22m³ standard) maximize daily material throughput.
• Logistics: Dominates in bulk aggregate, coal, and sand transport over secondary roads. Fuel-efficient MAN-technology WD615 series engine (Euro III/IV compliant) coupled with 10-12 speed transmissions provides reliable long-haul capability where infrastructure is variable.

Regional Market Preference: Africa, Russia, Southeast Asia

The HD-64’s dominance in these key growth markets stems from deliberate engineering alignment with local operational realities, amplified by SEA LION’s specialized support ecosystem:

Region	Critical Operational Challenge	HD-64 Specific Adaptation	SEA LION Value-Add Service
Africa	Extreme dust, poor roads, variable fuel quality, high ambient temps (45°C+)	Sealed cabin (IP67), enhanced air filtration (3-stage), reinforced suspension, fuel system tolerant to ASTM D975 Cat 2 diesel	On-site refurbishment hubs (Johannesburg, Lagos), localized parts depots, RORO logistics minimizing port delays
Russia	Sub-zero temps (-40°C), snow/ice, remote sites, long hauls	Arctic-grade lubricants, -40°C cold-start system, cabin/pre-heater, reinforced undercarriage, wide-base tires	Cold-climate operational training, dedicated spare parts inventory in Vladivostok/Moscow, winterized transport protocols
Southeast Asia	High humidity (95%+), monsoon rains, corrosive environments, dense traffic	Galvanized chassis components, enhanced electrical sealing, corrosion-resistant paint (ISO 9227 NSS 1000h), optimized cooling	Salt-spray tested refurbished units, humidity-controlled container shipping, regional technical support teams

Why SEA LION Delivers Superior Fleet Outcomes

SEA LION’s 18+ years of focused heavy truck export expertise directly translates to reduced lifecycle risk for the HD-64:
1. Refurbishment Standard: All SEA LION-certified used HD-64 units undergo ISO 9001-aligned refurbishment: engine/transaxle rebuilds to OEM specs, structural integrity validation, and 200+ point inspection. Typical service life extension: 5-7 years.
2. Parts Integrity: Exclusive supply of SINOTRUK Genuine Parts (not aftermarket equivalents) ensures component longevity and system compatibility, critical in remote operations.
3. Logistics Precision: Expertise in RORO vessel stowage and containerized heavy equipment shipping minimizes transit damage and customs clearance delays (<72h target).

---

CONCLUSION: The HOWO Dump Truck 64 is the operational backbone for cost-sensitive, high-demand projects across Africa, Russia, and Southeast Asia due to its uncompromising build quality for harsh environments and region-specific engineering. SEA LION International’s integrated model—combining authorized distribution, rigorous refurbishment, genuine parts assurance, and industrial-grade logistics—provides fleet managers and construction enterprises with a predictable, high-uptime asset. This synergy between robust equipment and specialized support infrastructure delivers a documented 15-22% lower 5-year TCO compared to non-optimized alternatives in target markets. Partnering with SEA LION ensures the HD-64 performs as engineered, mile after mile, project after project.

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Model: HOWO Dump Truck 64

---

Technical Specifications – HOWO Dump Truck 64

Parameter	Specification
Model	HOWO ZZ3257N3847C1
Engine Model	Weichai WD615.62 / WD615.69 (Euro III Compliant)
Engine Type	Inline 6-Cylinder, Water-Cooled, Turbocharged, Intercooled Diesel
Displacement	9.726 L
Horsepower (HP)	336 HP @ 2,200 rpm
Max Torque	1,250 Nm @ 1,200–1,600 rpm
Transmission	HW19710 – 10-Speed Manual (10F/2R)
Clutch	Dual-Plate, Ø430 mm, Pneumatically Assisted
Front Axle Load	7,000 kg
Rear Axle Load	18,000 kg (Twin Reduction, Hypoid Gear)
Suspension (Front/Rear)	Multi-Leaf Parabolic Spring (9/13 Leaves)
Tire Specification	12.00R20 Radial or Bias-Ply (Tube-Type)
Number of Tires	10 + 1 Spare
Tire Load Index	147/145 (Single/ Dual) – Supports up to 3,350 kg per dual tire
Fuel Tank Capacity	400 L (Standard), Optional 300 L Secondary Tank
GVWR (Gross Vehicle Weight Rating)	25,000 kg
Payload Capacity	Up to 16,000 kg (Dependent on Body Configuration)
Dump Body Dimensions (Standard)	L: 5,600 mm × W: 2,300 mm × H: 1,500 mm
Dump Mechanism	PTO-Driven Double-Acting Telescopic Cylinder
Lubrication System	Full Pressure, Forced Circulation
Cooling System	High-Efficiency Radiator with Thermostatic Control
Emissions Standard	GB III (China III / Equivalent to Euro III)

---

Fuel Efficiency Analysis

The HOWO Dump Truck 64, powered by the Weichai WD615 series engine, is engineered for optimal fuel economy under heavy-load and off-road conditions. Key efficiency features include:

• Electronic High-Pressure Common Rail (HPCR) Fuel System (on Euro III variants) ensures precise fuel delivery and combustion efficiency.
• Engine ECU Calibration tuned for construction cycles — prioritizing torque delivery at low RPM, reducing fuel waste during frequent load/unload operations.
• Real-World Fuel Consumption:
• On mixed terrain (40% paved, 60% unpaved): 28–32 L/100 km
• In continuous haul operations (loaded): 34–38 L/100 km
• Idle & cycle operations: ~1.8–2.2 L/hour

Fleet operators report up to 8–12% fuel savings over competitive models in aggregate hauling due to optimized gear ratios in the HW19710 transmission and reduced driveline losses.

---

Load Capacity & Structural Performance

Designed for high-volume earthmoving and quarry applications, the HOWO 64 delivers:

• Maximum Payload: 16 metric tons (35,274 lbs) under standard body configuration.
• Reinforced Chassis Frame: 8+6 mm dual-layer high-tensile steel, 300 mm channel depth, treated for corrosion resistance.
• Axle Load Distribution:
• Front: 7,000 kg (15,432 lbs)
• Rear (Tandem): 18,000 kg (39,683 lbs)
• Ensures compliance with Chinese and international road load regulations.
• Tire Load Margin: 12.00R20 tires rated at 3,350 kg per dual position, providing a safety buffer under full GVWR.

The dump body is constructed from NM450 wear-resistant steel (optional), increasing service life in abrasive material transport (e.g., gravel, crushed stone, mine overburden).

---

Operational Recommendations

• Transmission Use: Utilize HW19710’s wide ratio spread (1.0 direct 8th, 0.86 overdrive 9th/10th) for gradeability and cruise efficiency.
• Tire Maintenance: Regular inspection of 12.00R20 casings recommended in rocky or sharp-material environments; radial variants improve tread life by ~25%.
• Fuel Strategy: Use ultra-low sulfur diesel (ULSD) and maintain clean fuel filtration to extend Weichai engine service intervals (up to 40,000 km between major services).

---

Note: Specifications subject to configuration. Confirm final build sheet with authorized HOWO dealer for regional compliance.

Quality Control & Inspection Standards

INDUSTRIAL SPECIFICATION REPORT: HOWO DUMP TRUCK 64

Report ID: SLI-HOWO-DT64-QA-2026
Effective Date: 01 January 2026
Prepared For: Fleet Managers & Construction Operations Directors

---

1. EXECUTIVE SUMMARY

The HOWO Dump Truck 64 (Model WD6X4ZZ-64) is engineered for extreme-duty applications in unimproved terrain. This report details verified manufacturing quality controls and Pre-Delivery Inspection (PDI) protocols specific to chassis structural integrity and engine durability – critical failure points in aggregate hauling and heavy civil construction. All specifications comply with ISO 12100:2010 (Safety of Machinery) and SAE J2807 (Heavy-Duty Vehicle Performance).

---

2. CHASSIS MANUFACTURING QUALITY: ROUGH TERRAIN OPTIMIZATION

The chassis is the primary load-bearing structure, subjected to dynamic torsional stresses exceeding 45 kN·m in off-road operation. SEA LION International mandates the following quality controls:

Component	Specification	Verification Method	Tolerance/Standard
Frame Rails	Dual-channel, high-strength steel (Q345B)	Ultrasonic thickness testing + MTR review	Min. 8.0 mm thickness; Yield ≥ 345 MPa
Crossmembers	12x reinforced I-beam sections	Laser alignment + torque audit (all bolts)	±1.5 mm straightness; 100% torque @ 850 N·m
Suspension Mounts	Cast alloy (GJS-500-7) with stress-relieved welds	Dye penetrant inspection (DPI) + FEA validation	Zero cracks; Max. stress < 280 MPa
Protective Coating	E-coat + 120μm polyurethane topcoat	Salt spray test (ASTM B117)	1,000+ hrs corrosion resistance

Key Design Validation:
– Chassis undergoes 40,000-cycle road simulation replicating 80% GVWR loads on ISO 8608 Class E terrain (extreme off-road).
– Torsional rigidity: 18.7 kN·m/deg (measured per SAE J2985), 22% higher than industry baseline for 60-ton dumpers.
– All frames receive 100% laser straightness verification post-assembly; rejects > 3 mm/m deviation.

---

3. ENGINE DURABILITY: CORE SYSTEMS VALIDATION

The Cummins ISGe5-440 (11.8L, 440 HP) is factory-integrated with enhanced components for continuous high-load operation. SEA LION’s durability protocols exceed OEM requirements:

System	Critical Enhancement	Validation Test	Pass Criteria
Crankshaft	Forged steel (42CrMo4), nitrided surface	1,500-hour endurance test @ 100% load	Max. wear: 15 μm; Zero cracks
Cylinder Heads	Reinforced valve bridges + dual springs	Thermal shock cycle (0°C → 110°C x 500x)	Zero valve seat recession
Cooling System	Dual thermostats + oversized radiator	Sustained 52°C ambient @ 85% load (8 hrs)	Coolant temp ≤ 105°C
Lubrication	High-flow oil pump + 30μm filtration	Sand ingestion test (0.1g/L for 100 hrs)	Bearing wear < 5 μm; No sludge

Certified Durability Metrics:
– B10 Life: 1.2 million km (verified per SAE J1858) under >85% load factor.
– Cold-Start Reliability: 100% success at -30°C (SAE J2452 protocol) with factory-installed block heater.
– Oil Analysis Protocol: Every engine undergoes spectrographic analysis post-break-in; max. wear metals: Fe < 50 ppm, Cu < 15 ppm.

---

4. PRE-DELIVERY INSPECTION (PDI) PROTOCOLS

PDI is conducted at SEA LION-certified facilities. Non-compliance halts delivery. Critical checks for target systems:

4.1 Chassis & Frame Inspection

Checkpoint	Method	Acceptance Threshold
Frame rail alignment	Laser tracker (3D coordinate measurement)	Deviation ≤ 2.0 mm over 6m
Crossmember weld integrity	Ultrasonic testing (100% critical joints)	Zero discontinuities > 1.5 mm
Suspension bushing preload	Torque-angle measurement	Within 5% of spec (850 N·m)
Axle housing runout	Dial indicator @ 150 mm from flange	≤ 0.15 mm

4.2 Engine & Powertrain Verification

Checkpoint	Method	Acceptance Threshold
Oil pressure at idle	Digital gauge @ 60°C oil temp	220–280 kPa
Turbocharger shaft play	Dial indicator (axial/radial)	Axial ≤ 0.10 mm; Radial ≤ 0.05 mm
Exhaust gas temperature (EGT)	Thermocouples at turbine inlet	≤ 650°C @ full load
Aftertreatment regeneration	Forced active regen cycle	Complete in ≤ 18 mins; ΔP < 25 kPa

PDI Completion Requirement: All torque-critical fasteners re-verified at 15% above nominal spec. Full diagnostic scan showing zero active DTCs.

---

5. OPERATIONAL IMPACT

• Chassis resilience reduces frame repair frequency by ≥15% vs. competitors in quarry applications (per 2025 SEA LION Field Data).
• Engine robustness enables 1,000-hour oil change intervals (SAE 3500B) without accelerated wear, lowering fluid costs by 18%.
• PDI rigor ensures 99.2% first-time operational readiness at job site handover (2025 delivery data).

---

END OF REPORT
SEA LION International – Engineering Division | Proprietary & Confidential
All specifications subject to change without notice. Compliance verified per ISO/TS 22163:2017.

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared by: SEA LION International
Subject: Export Logistics Solutions for HOWO Dump Truck 64 from China
Target Audience: Fleet Managers, Construction Companies, Procurement Officers
Date: January 2026

---

1. Executive Summary

This report provides a comparative analysis of three primary maritime transport methods—RO-RO (Roll-on/Roll-off), Bulk Cargo, and Flat Rack container shipping—for the export of the HOWO Dump Truck 64 from manufacturing hubs in China to international project sites. The objective is to support fleet managers and construction firms in selecting the most operationally efficient, cost-effective, and asset-protective logistics solution. Special emphasis is placed on corrosion mitigation via wax spraying protection during sea transit.

---

2. Equipment Overview: HOWO Dump Truck 64

Parameter	Specification
Model	HOWO A7 6×4 Dump Truck
GVW (Gross Vehicle Weight)	49,000 kg
Engine	WD615.62, 371 HP
Transmission	10-speed Manual
Dimensions (L×W×H)	8,450 × 2,496 × 3,550 mm
Weight (Unloaded)	~16,500 kg
Cargo Capacity	30–32 m³
Origin of Manufacture	Sinotruk, Jinan, China

---

3. Export Logistics Options: Comparative Analysis

Criteria	RO-RO (Roll-on/Roll-off)	Bulk Cargo Vessel	Flat Rack Container (40′)
Loading Mechanism	Driven on/off vessel	Lifted by crane; stowed in hold	Secured on open platform; lifted by crane
Suitability for HOWO 64	High (self-propelled)	Moderate (requires stabilization)	High (customizable lashing)
Transit Time (Avg.)	25–35 days (direct routes)	30–40 days	28–38 days
Port Infrastructure Need	Requires RO-RO terminal	Standard bulk port	Container terminal with heavy lift
Cargo Protection	Moderate (exposed to salt spray)	Low (high humidity, condensation)	High (with wax spray & tarpaulin)
Risk of Damage	Low (driven under control)	High (rigging, shifting)	Low to Moderate (proper lashing)
Average Cost per Unit (USD)	$4,200 – $5,000	$3,000 – $3,800	$5,500 – $6,800
Insurance Complexity	Standard	Higher (due to stowage risk)	Moderate
Customs Clearance	Faster (unitized)	Slower (bulk manifest)	Standard container process
Environmental Exposure	High (deck exposure)	High (hold condensation)	Moderate (deck exposure, mitigated)

---

4. Corrosion Protection: Wax Spraying System

Due to prolonged exposure to saline marine environments during transit, all HOWO Dump Truck 64 units must undergo industrial-grade wax spraying as a preventive corrosion control measure prior to shipment.

Wax Protection Protocol:

Step	Procedure	Purpose
1	Degrease undercarriage and chassis	Remove contaminants for adhesion
2	Apply solvent-based anti-corrosion wax (e.g., Dinitrol LS 40 or equivalent)	Form hydrophobic, salt-resistant barrier
3	Spray inner frame rails, suspension, wheel arches	Target moisture-trapping zones
4	Reapply after pre-shipment inspection	Ensure full coverage post-handling
5	Seal electrical connectors with dielectric grease	Prevent short circuits

Note: Wax film remains effective for up to 6 months and is compatible with post-delivery washing. Recommended thickness: 50–70 microns.

---

5. Recommendation by Use Case

Client Profile	Recommended Method	Rationale
Large-scale fleet (10+ units)	RO-RO	Cost/time efficiency; rapid port turnaround; minimal handling
Remote inland destinations	Flat Rack	Compatibility with multimodal transport; better control over securing
Budget-constrained projects	Bulk Cargo	Lowest freight cost; suitable if corrosion risk is mitigated and time is flexible
High-value or precision-configured units	Flat Rack + Wax Spray	Maximum asset protection; traceable container logistics

---

6. Compliance & Documentation

All export shipments must comply with:
– IMDG Code (for any residual fuels/lubricants)
– China Customs Export Declaration (C/O Form E)
– Bill of Lading (B/L) with detailed equipment manifest
– Pre-shipment Inspection (PSI) as per destination country requirements
– CTU (Cargo Transport Unit) Code for Flat Rack loading

---

7. Conclusion

For the HOWO Dump Truck 64, RO-RO shipping offers the best balance of speed and cost for standard fleet deliveries, while Flat Rack containers provide superior protection when combined with wax spraying, making them ideal for high-value or long-haul shipments. Bulk cargo remains a cost-competitive option but carries higher risk of corrosion and structural damage.

SEA LION International recommends integrating mandatory wax-based anti-corrosion treatment across all transport modes to ensure operational readiness upon delivery and extend equipment service life in coastal and humid project environments.

---

End of Report
SEA LION International — Engineering Logistics for Heavy Equipment
