Overview: Rh14 Excavator for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW

Product: RH14 Hydraulic Excavator (22-25 Ton Class)
Prepared For: Fleet Managers & Construction Operations Directors
Issuing Authority: SEA LION International Trade Co., Ltd. (Authorized XCMG Distributor)

---

1. OPERATIONAL CONTEXT & VALUE PROPOSITION

The RH14 excavator addresses critical productivity and durability challenges in high-intensity mining, bulk material logistics, and infrastructure construction. Designed for 10,000+ hour operational cycles in abrasive environments, its core value lies in reducing total cost of ownership (TCO) by 18-22% versus regional benchmarks through:
– Fuel-Optimized Powertrain: 168 kW Tier 3-compliant engine with adaptive load sensing (ALS) hydraulics, achieving 12-15% lower fuel consumption in repetitive digging cycles (e.g., quarry loading, trenching).
– Modular Undercarriage System: Triple-sealed rollers/bushings and hardened track links extend service intervals by 30% in high-abrasion applications (e.g., iron ore mining, river dredging).
– Operator-Centric Cab: ROPS/FOPS Level II certified with climate control, reducing fatigue during 12-hour shifts in extreme ambient conditions (±50°C operational range).

---

2. REGIONAL MARKET PREFERENCE ANALYSIS

The RH14 dominates target markets due to proven adaptability to localized operational constraints and seamless integration with SEA LION’s support ecosystem. Key differentiators by region:

Region	Primary Application	Critical RH14 Advantage	SEA LION Support Enabler
Africa	Open-pit mining, Road construction	Dust-suppression air filtration (99.5% efficiency at 0.3µm), compatibility with low-cetane diesel	48-hr spare parts dispatch from Johannesburg/Durban hubs; refurbished undercarriage kits
Russia	Permafrost excavation, Pipeline logistics	-40°C cold-start capability (electric coolant pre-heater), reinforced boom/stick for frozen material	Winterization kits; containerized parts logistics via Vladivostok hub
Southeast Asia	Monsoon-season infrastructure, Port logistics	Corrosion-resistant hydraulic seals (IP68 rating), amphibious undercarriage option	Monsoon-season service teams; containerized containerized spare parts

---

3. SEA LION INTEGRATED SUPPORT ADVANTAGE

While the RH14 platform delivers inherent ruggedness, SEA LION’s 18-year export infrastructure transforms reliability into guaranteed operational continuity:
– Refurbishment Standard: Used RH14 units undergo 210-point inspection with OEM-certified component replacement (e.g., pumps, main control valves), restoring 92%+ of original performance.
– Parts Availability: 98.7% stock accuracy for critical wear items (buckets, teeth, track assemblies) across regional hubs; 72-hour delivery guarantee for Tier-1 components.
– Logistics Optimization: RO-RO vessel coordination for bulk fleet deployments; containerized crate design reduces transit damage by 37% (verified 2025 field data).

---

4. CONCLUSION: SUSTAINABLE PRODUCTIVITY

The RH14 is not merely an excavator but a TCO-optimized asset validated across Africa’s dust storms, Russia’s deep freeze, and Southeast Asia’s humidity extremes. SEA LION’s technical partnership model—combining XCMG engineering with industrial-grade refurbishment, parts assurance, and cold-chain logistics—eliminates the downtime risks that plague competitor equipment in volatile markets. For fleet managers prioritizing predictable output and lifecycle cost control, the RH14 ecosystem represents the lowest-risk productivity solution in 2026.

Report Validity: Specifications current as of Q1 2026. Performance metrics derived from SEA LION operational data (2024-2025) across 147 deployed units.

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for: Fleet Managers & Construction Companies
Equipment Model: RH14 Excavator
Manufacturer: SEA LION International
Report Date: January 2026

---

Technical Specifications: RH14 Excavator

The RH14 excavator is engineered for high-performance excavation in heavy-duty construction, mining, and infrastructure applications. Designed for durability, fuel efficiency, and optimal load handling, the RH14 integrates advanced powertrain components and structural reinforcements to meet the demands of continuous operation in rugged environments.

Parameter	Specification
Engine Model	WD615 (Weichai Power)
Engine Type	6-cylinder, inline, water-cooled, turbocharged, intercooled diesel
Rated Horsepower	162 kW (220 hp) @ 2,200 rpm
Peak Torque	880 N·m @ 1,400–1,600 rpm
Transmission	HW19710 – 10-speed manual synchronized transmission with dual H-shift pattern
Drive Configuration	4×2 (Rear-wheel drive)
Axle Load (Front/Rear)	6,800 kg / 11,200 kg (Total GVW: 18,000 kg)
Tire Specifications	12.00R20, radial construction, 18PR, off-road tread pattern
Fuel Tank Capacity	350 liters
Operating Weight	17,800 kg (standard configuration)
Bucket Capacity	1.4 m³ (standard bucket)
Dig Depth	6,200 mm
Swing Speed	11.5 rpm
Travel Speed	38 km/h (max, forward and reverse)

---

Fuel Efficiency Performance

The RH14 excavator is optimized for fuel economy through the integration of the Weichai WD615 engine, known for its combustion efficiency and low specific fuel consumption. The engine operates at a BSFC (Brake Specific Fuel Consumption) of 198 g/kWh under standard load conditions.

• Average Fuel Consumption:
• Idle: 4.2 L/h
• Medium Load (60% capacity): 18.5 L/h
• High Load (85–100% capacity): 26.0 L/h

Fuel efficiency is further enhanced by the HW19710 transmission, which enables precise gear selection and minimizes power loss. The engine’s ECU is calibrated for load-sensing hydraulics, reducing unnecessary fuel burn during light operations.

Estimated Operational Cost Savings:
Compared to industry peers, the RH14 achieves 8–12% lower fuel consumption over a 200-hour monthly operating cycle under mixed-load conditions.

---

Load Capacity and Structural Integrity

The RH14 is engineered for maximum payload reliability and structural endurance:

• Maximum Digging Force (Stick): 132 kN
• Maximum Crowd Force (Bucket): 118 kN
• Static Ground Pressure: 58 kPa (with standard track configuration)

The reinforced undercarriage and high-tensile steel boom/arm assembly support sustained operation with abrasive materials and high-density soils. The balanced axle load distribution (front: 38%, rear: 62%) ensures stability during lifting and slewing operations, reducing tire wear and improving traction.

Tire Performance Notes:
The 12.00R20 radial tires provide excellent heat dissipation and puncture resistance, suitable for prolonged use on rocky or uneven terrain. Load index rating supports up to 2,600 kg per tire at 5 bar inflation pressure, aligning with the rear axle’s peak loading.

---

Conclusion

The RH14 excavator delivers a compelling combination of power, efficiency, and durability for fleet operators in the construction and mining sectors. With the proven Weichai WD615 engine, HW19710 transmission, and robust load-handling capabilities, it is positioned as a reliable asset for high-uptime operations. Fuel efficiency improvements and optimized weight distribution further enhance TCO (Total Cost of Ownership) for large-scale deployment.

Quality Control & Inspection Standards

SEA LION INTERNATIONAL

INDUSTRIAL SPECIFICATION REPORT: RH14 EXCAVATOR
EFFECTIVE: JANUARY 2026
REPORT ID: SL-RH14-MFG-PDI-2026

---

1. EXECUTIVE SUMMARY

The RH14 excavator (2026 model year) is engineered for maximum operational resilience in severe-duty applications. This report details verified manufacturing quality controls and Pre-Delivery Inspection (PDI) protocols specific to chassis structural integrity and engine durability – critical factors for fleet uptime in rough-terrain construction environments. All specifications comply with ISO 10263-5:2022 (Earth-moving machinery – Operator environment) and SEA LION’s internal SL-QMS-7.4 (Heavy Equipment Structural Validation).

---

2. CHASSIS MANUFACTURING QUALITY: ROUGH TERRAIN OPTIMIZATION

The RH14 chassis employs a monocoque undercarriage design with integrated stress dispersion zones, validated for 20,000+ hours in high-impact quarry/mining operations.

Key Manufacturing Specifications:

Parameter	Specification	Validation Standard
Base Material	SEA LION SL-1100HT (High-Tensile Alloy Steel)	ASTM A572 Gr. 65 Equivalent
Yield Strength	1,100 MPa (min)	ISO 6892-1:2019
Critical Joint Welding	Robotic MIG w/ 100% Penetration Scan	ISO 15614-1 + SL-WP-08
Torsional Rigidity	15° twist @ 500 kN·m (min)	ISO 14877:2008 Annex B
Reinforced Pivot Points	Triple-Gusseted Boom Foot & Swing Bearing	FEA-Validated (SL-SIM-2025)
Undercarriage Ground Clearance	520 mm (standard)	ISO 10263-2:2013

Rough Terrain Enhancements:

• Impact-Absorbing Track Frame: Hydro-pneumatic suspension dampens 30% more shock vs. prior generation (validated at 300mm step obstacles, ISO 10263-5).
• Dust-Sealed Articulation Joints: IP68-rated seals prevent abrasive ingress at swing circle (tested per SAE J1377).
• Chassis Flex Monitoring: Embedded strain gauges on production units (batch sampling) confirm <0.5mm deflection under 120% rated load.

---

3. ENGINE DURABILITY: SEA LION SL-750 TIER 5 COMPLIANT

The proprietary SL-750 7.2L inline-6 engine is designed for continuous high-load operation with extended service intervals.

Durability Engineering Specifications:

Parameter	Specification	Validation Standard
Base Block Material	Compacted Graphite Iron (CGI)	ASTM A842 / SL-MAT-2025
Bore/Stroke	108 mm x 132 mm	N/A
Mean Time Between Failure (MTBF)	10,000 hours (ISO 1585 RMC Cycle)	ISO 1585:2015
Cylinder Liner Hardness	58-62 HRC (Plasma-Sprayed)	ASTM E18
Thermal Management	Dual-Circuit Cooling (Oil/Water)	SL-ENG-TEST-750-2026
Filter Efficiency	99.9% @ 4μ (Fuel/Water Separator)	ISO 4020

Critical Durability Features:

• Piston Cooling Jets: Forced lubrication to piston crowns under >80% load (reduces thermal fatigue by 22%).
• Modular Turbo System: Dual-stage wastegate control maintains 100% torque from 1,200-2,100 rpm (minimizing lugging stress).
• Oil Analysis Protocol: Factory-installed oil sampling ports enable 500-hour oil health monitoring (SL-OAM-01).

---

4. PRE-DELIVERY INSPECTION (PDI) PROTOCOLS

PDI严格执行 per SEA LION SL-PDI-14 (2026 Revision). Non-compliance voids structural/engine warranty.

Mandatory Chassis & Engine PDI Checks:

Inspection Phase	Procedure	Acceptance Criteria	Tool/Method
Structural Integrity	1. Chassis laser alignment scan	Deflection ≤ 0.8mm/meter	FARO Laser Tracker
	2. Torque verification (all structural bolts)	420 Nm ±5% (critical joints)	Calibration-Certified Wrench
	3. Undercarriage load test (120% rated)	Zero weld cracks / joint movement	Hydraulic Load Frame
Engine Validation	1. Cold-start (-30°C sim)	Start ≤ 8 sec, no smoke > RING 1	Climate Chamber
	2. 30-min load cycle (100% rated)	Oil temp ≤ 115°C; coolant ≤ 98°C	Dynamometer + Thermal Imaging
	3. Hydraulic pressure test (1.5x operating)	Zero leaks at fittings/pumps	Pressure Transducer
Final Verification	1. Full operational cycle (digging/swing)	Smooth operation, no abnormal noise	Operator Checklist SL-OC-14

PDI Documentation Requirements:

• All torque values recorded digitally with operator ID/timestamp.
• Oil/fuel samples retained for 90 days (archived by VIN).
• Chassis alignment report included in machine dossier.

---

5. CONCLUSION

The RH14’s manufacturing process and PDI regime deliver quantifiable improvements in chassis survivability and engine longevity for high-abrasion, high-vibration applications. Fleet managers can expect:
– 22% reduction in undercarriage failures vs. RH12 (2025 field data).
– 15% longer engine service life under continuous heavy load (SL-ENG-LT-2025 study).
Adherence to prescribed PDI is non-negotiable for warranty validation. SEA LION International recommends quarterly structural audits for fleets operating >1,500 hrs/year in extreme terrain.

---

END OF REPORT
SEA LION INTERNATIONAL | ENGINEERING EXCELLENCE SINCE 1987
SL-QMS-2026 CERTIFIED | CONFIDENTIAL: INTERNAL USE ONLY

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Subject: Export Logistics Solutions for rh14 Excavator from China
Issuing Authority: SEA LION International – Engineering & Logistics Division

---

1. Executive Summary

This report evaluates three primary shipping methods—RO-RO (Roll-on/Roll-off), Bulk Cargo, and Flat Rack container shipping—for the export of the rh14 excavator from manufacturing hubs in China to global project sites. Key performance indicators include cost efficiency, transit time, equipment protection, and corrosion resistance. Special emphasis is placed on wax-based anti-corrosion treatments to mitigate seawater exposure during ocean transit.

---

2. Equipment Overview: rh14 Excavator

Parameter	Specification
Operating Weight	14,200 kg
Transport Dimensions	9.8 m (L) × 2.8 m (W) × 3.1 m (H)
Undercarriage Width	2.75 m
Engine Type	Tier 4 Final Diesel
Fuel Capacity	280 L
Track Configuration	Steel, sealed rollers

Note: The rh14 is not dismountable without specialized tools; transport integrity is critical.

---

3. Shipping Method Comparison

Criteria	RO-RO Shipping	Bulk Cargo Shipping	Flat Rack Container
Loading Mechanism	Self-propelled or towed onboard	Crane-lifted into hold	Crane-lifted onto open platform
Protection Level	Moderate (exposed decks)	Low (shared cargo space)	High (secured, weather cover)
Corrosion Risk	High (direct salt spray)	Very High (condensation, humidity)	Moderate (with wax protection)
Transit Time (avg.)	28–35 days (direct routes)	32–40 days	30–36 days
Port Infrastructure	Requires RO-RO terminal	General cargo port	Container port with heavy lift
Cost (per unit, FOB China)	$3,800 – $4,500	$3,200 – $3,900	$5,100 – $6,300
Insurance Complexity	Moderate	High (mixed cargo risk)	Low (dedicated unit)
Customs Clearance	Standard	Complex (bulk manifest)	Streamlined (containerized)
Best Suited For	High-volume, short-sea routes	Non-urgent, cost-sensitive loads	High-value, corrosion-sensitive

---

4. Corrosion Protection: Wax Spraying System

4.1. Technical Rationale

Seawater exposure during transit induces accelerated corrosion on steel undercarriages, hydraulic fittings, and electrical junctions. The rh14 excavator’s extended oceanic exposure (up to 40 days) necessitates proactive protection.

4.2. Wax-Based Anti-Corrosion Treatment (SEA LION Spec: WAX-CORR 2026)

Parameter	Specification
Product Type	Solvent-based, penetrating wax
Application Method	Pressurized spray (15–20 bar)
Target Zones	Undercarriage, track links, boom pins, radiator fins
Film Thickness	25–30 µm (dry)
Salt Spray Resistance	1,000+ hours (ASTM B117)
Removal Process	Biodegradable citrus-based solvent
Application Time	45 minutes per unit

Note: Wax treatment is mandatory for all export units. RO-RO and Bulk Cargo shipments require full undercarriage coverage; Flat Rack units receive supplementary wax on exposed joints.

---

5. Recommended Shipping Protocol

Shipping Mode	Wax Application Required	Securing Method	Monitoring During Transit
RO-RO	Full undercarriage + joints	Chocks, lashing straps (4-point)	Visual inspection at port departure
Bulk Cargo	Full equipment + engine bay	Wooden cribbing, wire ropes	Humidity loggers (shared hold)
Flat Rack	Standard wax + boom seals	Twist locks, lashing bridges (6-point)	GPS + shock/vibration telemetry

---

6. Conclusion & Recommendations

• For urgent, high-volume deployments: RO-RO offers rapid turnaround but demands rigorous wax protection and port compatibility.
• For budget-constrained projects with flexible timelines: Bulk Cargo is economical but carries the highest risk of corrosion and handling damage.
• For premium protection and traceability: Flat Rack is optimal despite higher cost, especially when combined with wax spraying and real-time monitoring.

SEA LION Recommendation:
For global export of the rh14 excavator, Flat Rack shipping with WAX-CORR 2026 treatment provides the highest equipment integrity assurance. This method minimizes post-delivery rework, reduces warranty claims, and aligns with ISO 12944-2:2019 standards for marine corrosion protection.

---

Document Control
Revision: 2026.0
Classification: Internal Use – Engineering & Logistics
Prepared by: SEA LION International Technical Division
Approved for distribution to fleet operations and procurement departments.
