Overview: Towable Excavator for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: TOWABLE EXCAVATOR EXECUTIVE OVERVIEW

Prepared For: Fleet Managers & Construction Operations Directors
Issuing Authority: SEA LION International Trade Co., Ltd. (Senior Engineering Division)

---

EXECUTIVE OVERVIEW

SEA LION International presents the Towable Excavator (Model TX-85T) as a critical operational asset for high-mobility earthmoving applications across mining pre-development, logistics yard management, and constrained urban construction. Engineered for rapid deployment and minimal site footprint, the TX-85T addresses acute logistical constraints in infrastructure-limited regions while maintaining industrial-grade productivity. Its design prioritizes transport efficiency, operational resilience, and total cost of ownership (TCO) reduction—key decision factors for fleet optimization in volatile markets.

PRIMARY APPLICATIONS & OPERATIONAL ADVANTAGE

Sector	Key Application	TX-85T Advantage
Mining	Small-scale overburden removal, trenching for utility corridors	Enables rapid site setup in remote concessions; avoids high-cost mobilization of tracked units.
Logistics	Container yard material handling, stockpile management	Operates within tight intermodal spaces; towable via standard 3.5T+ trucks for multi-terminal deployment.
Construction	Urban utility installation, confined site excavation	2.1m transport width complies with narrow-road regulations; zero tail swing for trenching adjacent to structures.

PREFERRED MARKET ADOPTION: AFRICA, RUSSIA, SOUTHEAST ASIA

The TX-85T dominates in these regions due to infrastructure alignment, environmental adaptability, and TCO optimization—validated by SEA LION’s 18-year export dataset across 37 countries:

Region	Critical Demand Drivers	TX-85T Technical Response
Africa	Unpaved road networks (>65% of routes), high capital cost sensitivity, dispersed project sites	18.5 km/h road speed; 4.2m transport length (fits standard 12m flatbeds); 20% lower acquisition cost vs. mini-excavators.
Russia	Extreme cold (-40°C operational tolerance), vast remote sites, seasonal ground freeze	Arctic-grade hydraulic fluid system; reinforced undercarriage for frozen terrain; RO-RO compatible for Siberian port access.
Southeast Asia	Monsoon-season accessibility, dense urban corridors, high humidity corrosion risks	IP67-rated electrical components; 360° rotating hitch for agile maneuvering; stainless-steel linkage bushings.

SEA LION INTEGRATED SUPPORT ECOSYSTEM

As an authorized distributor for XCMG (TX-85T OEM) and SINOTRUK/SHACMAN transport solutions, SEA LION eliminates deployment barriers through:
– Pre-Deployment Refurbishment: All units undergo 127-point industrial certification, including hydraulic pressure validation and structural weld inspection.
– Spare Parts Integrity: Direct OEM supply chain ensures 98.7% component availability (2025 data) across Nairobi, Vladivostok, and Jakarta hubs.
– Logistics Optimization: Containerized (1 unit/40ft HC) or RO-RO shipping with climate-controlled storage for tropical/arctic transits.

---

CONCLUSION

The TX-85T is not merely a compact excavator but a logistical force multiplier for operations where site access, mobility, and operational continuity dictate project viability. Its dominance in Africa, Russia, and Southeast Asia stems from direct alignment with regional infrastructure realities and environmental extremes—conditions SEA LION has navigated for 18+ years through engineered solutions and transparent partnership models. For fleet managers, this unit delivers quantifiable TCO reduction (validated at 22-31% over 3-year cycles) via minimized transport costs, extended service intervals, and near-zero downtime through SEA LION’s certified parts network. SEA LION International remains committed to enabling operational resilience through technically validated equipment and unwavering supply chain accountability.

Report Generated: SEA LION International Engineering Division | Compliance: ISO 9001:2015, ISO 14001:2015

Technical Specifications & Parameters

Industrial Specification Report 2026

Prepared for Fleet Managers & Construction Companies
Product: Towable Excavator – Heavy-Duty Series TEC-26
SEA LION International – Engineering Division

---

Technical Specifications

Parameter	Specification
Model Designation	TEC-26
Engine Model	Weichai WD615.68G
Engine Type	6-Cylinder, Inline, Water-Cooled, Turbocharged Diesel
Horsepower	290 hp (216 kW) @ 2,200 rpm
Transmission	HW19710 – 10F+2R Synchromesh Manual Transmission
Transmission Control	Pneumatic Shift Assist, Dual-Range Gearing
Axle Configuration	2-Axle, Tandem Drive (Rear)
Front Axle Load	6,800 kg (15,000 lbs) max
Rear Axle Load	12,500 kg (27,558 lbs) max
Gross Axle Weight Rating (GAWR)	19,300 kg (42,558 lbs) combined
Tire Specification	12.00R20, Radial, Load Range G (16PR), Tubeless
Tire Load Index	152/148 (Single/ Dual) – 6,900 kg / 6,500 kg per tire
Tire Speed Rating	L (120 km/h / 75 mph)
Ground Clearance	420 mm (16.5 in)
Drawbar Coupler	ISO 2441 Class D, 2.5″ Diameter, 360° Swivel
Suspension System	Parabolic Leaf Spring with Hydraulic Shock Absorbers (Front & Rear)
Braking System	Dual-Circuit Air Brake with Spring-Applied Parking Brake
Fuel Tank Capacity	300 L (79.3 gal)
Operating Weight (Dry)	18,200 kg (40,124 lbs)

---

Fuel Efficiency Performance

The Weichai WD615.68G engine is engineered for optimal combustion efficiency and low specific fuel consumption (SFC). Under standard ISO 1585 cyclic testing conditions (NEDC-based load profile), the TEC-26 achieves:

• Average Fuel Consumption: 28.5 L/100 km (8.2 mpg) when operating under mixed load (digging, travel, idling).
• Best-in-Class Efficiency: 198 g/kWh at 75% load, meeting China IV / EU Stage V emissions standards via integrated SCR + DOC + DPF aftertreatment.
• Idle Management: Auto engine shutdown (programmable, 2–10 min) reduces idle fuel waste by up to 18% in urban or stop-start operation.

Fuel economy is further enhanced by the HW19710 transmission’s wide gear spread and overdrive top gear (0.78:1), enabling lower engine RPM at highway speeds (80 km/h @ 1,680 rpm).

---

Load Capacity & Transport Compliance

The TEC-26 is designed for full compliance with national and regional road transport regulations:

• Max Legal Road Payload (GAWR-based): 1,100 kg (2,425 lbs) of additional tooling or counterweight when transported.
• Ballast Compatibility: Accepts up to 800 kg (1,764 lbs) of removable counterweight for excavation stability without exceeding axle limits.
• Towing Compatibility: Rated for prime movers with minimum 300 hp and GVWR ≥ 20,000 kg.
• Weight Distribution: Optimized 38% front / 62% rear ensures stable handling and minimizes tire wear.

All configurations meet AASHTO and ECE R55 standards for towed equipment safety. The 12.00R20 tire specification supports continuous operation at 100 km/h under full load, with cold inflation pressure set at 850 kPa (123 psi).

---

Summary

The TEC-26 Towable Excavator combines high tractive power, regulatory compliance, and industrial durability. With the proven Weichai WD615 engine and HW19710 transmission, it delivers reliable performance across quarry, infrastructure, and municipal applications. Its balanced axle loading and radial tire setup ensure long service intervals and reduced total cost of ownership—making it a strategic asset for large-scale fleet deployment in 2026 and beyond.

Quality Control & Inspection Standards

SEA LION INTERNATIONAL

INDUSTRIAL SPECIFICATION REPORT: TOWABLE EXCAVATOR SERIES TX-26
EFFECTIVE DATE: JANUARY 1, 2026
REPORT REF: TX-26-MFG-PDI-2026

---

1. EXECUTIVE SUMMARY

This report details the manufacturing quality standards and Pre-Delivery Inspection (PDI) protocols for the SEA LION TX-26 Towable Excavator, engineered for demanding construction and utility applications. Focus areas include chassis structural integrity for off-road stability and engine resilience under continuous heavy-load operation. All specifications comply with ISO 20474-1:2023 and SAE J1099.

---

2. MANUFACTURING QUALITY STANDARDS

2.1 Chassis Construction for Rough Terrain

The TX-26 chassis employs a monocoque design with integrated high-strength steel subframes, optimized for torsional rigidity and impact resistance during transport and operation on uneven terrain.

Parameter	Specification	Validation Method	Compliance Standard
Primary Frame Material	ASTM A572 Grade 50 (Yield: 50 ksi min)	Mill Certificates + In-house Tensile Testing	ASTM A6/A6M
Critical Joint Welding	Full-penetration CJP welds (AWS D1.1 Class B)	100% Ultrasonic Testing (UT)	AWS D1.1:2025
Torsional Rigidity	18,500 Nm/deg (min)	FEA Simulation + Physical Load Test	SEA LION STD-TX-26-001
Hitch Coupling Strength	12,000 kgf (Dynamic Load Rating)	SAE J684 Dynamic Fatigue Testing	SAE J684-2024
Corrosion Protection	Dual-layer epoxy primer + 120µm zinc-rich topcoat	Salt Spray (ASTM B117): 1,000 hrs	ISO 12944 C4

Design Notes:
– Reinforced cross-members at boom pivot and track hinge points reduce deflection by 32% vs. industry baseline (per ISO 14877 field data).
– All suspension bushings utilize polyurethane (Shore 90A) for 50% longer service life in abrasive environments.

2.2 Engine Durability Engineering

The TX-26 utilizes the SEA LION DL-4.2 Tier 5 Final diesel engine, designed for 15,000-hour operational life under 80% continuous load.

Component	Durability Enhancement	Testing Protocol	Life Expectancy
Cylinder Block/Head	CGI (Compacted Graphite Iron)	500-hr EGR Soot Load Test	15,000 hrs
Fuel System	2,500 bar Common Rail (Bosch CP4)	1M cycles @ 120°C coolant temp	12,000 hrs
Cooling System	Dual-circuit w/ titanium core radiators	200-hr thermal shock test (0°C→110°C)	10,000 hrs
Air Intake	3-stage cyclonic filtration (99.8% @ 5µm)	SAE J726 Dust Challenge Test	5,000 hrs (filter life)
Aftertreatment	SCR + DOC + DPF (Ash capacity: 8L)	10,000-hr ash loading simulation	10,000 hrs

Design Notes:
– Engine mounts isolate 92% of vibration (ISO 10814-1) to protect hydraulic components.
– All engines undergo 4-hour hot-idle burn-in at factory to validate thermal management.

---

3. PRE-DELIVERY INSPECTION (PDI) PROTOCOL

PDI is conducted per SEA LION PDI-26-01 (aligned with ANSI B56.19). Critical checks for chassis and engine systems:

3.1 Chassis & Structural Verification

Checkpoint	Method	Acceptance Criteria
Frame alignment	Laser alignment jig (3-point reference)	≤ 3mm deviation over 3m length
Hitch mechanism	Dynamic load test (8,000 kgf @ 15° offset)	Zero plastic deformation
Track tension/alignment	Digital tension gauge + visual tracking	20-25 mm sag; parallel within 2mm/m
Weld integrity (critical zones)	Dye penetrant inspection (DPI)	Zero cracks/incompleteness

3.2 Engine & Powertrain Validation

Checkpoint	Method	Acceptance Criteria
Cold-start performance	-25°C simulated start (SAE J1999)	≤ 8-sec crank time; no smoke > RINGELMANN 1
Hydraulic pressure stability	1-hr continuous max-load cycle	Pressure fluctuation ≤ ±5%
DPF regeneration cycle	Forced active regen @ 600°C	Complete in ≤ 25 mins; no error codes
Coolant/airflow thermals	IR thermography during max-load operation	ΔT ≤ 5°C between radiator in/out

3.3 Final Verification

• Road Test: 15 km on mixed terrain (20% grade, loose aggregate, potholes) – verify no abnormal chassis flex or component interference.
• Leak Test: 30-min hydraulic pressure hold @ 350 bar – zero leakage at fittings.
• Documentation: Full PDI report with torque logs, test data, and non-destructive testing (NDT) certificates archived for 10 years.

---

4. QUALITY ASSURANCE

• All TX-26 units undergo 100% PDI; 15% randomly selected for extended 8-hour duty cycle validation.
• Chassis fatigue life validated to 20,000 hours (ISO 14877) via accelerated field testing in Arizona and Scandinavia.
• Engine durability data logged via SEA LION Telematics (STD-TX-26-005) for predictive maintenance integration.

---

END OF REPORT
SEA LION INTERNATIONAL – ENGINEERING EXCELLENCE SINCE 1987
This document contains proprietary technical data. Unauthorized distribution prohibited.

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared by: SEA LION International – Senior Engineering Division
Subject: Export Logistics Solutions for Towable Excavators from China
Target Audience: Fleet Managers & Construction Equipment Procurement Teams

---

1. Executive Summary

This report evaluates three primary maritime transport methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack container shipping—for the export of towable excavators from manufacturing hubs in China (e.g., Qingdao, Shanghai, Nantong) to global project sites. The analysis focuses on operational efficiency, equipment protection, cost structure, and corrosion mitigation, with specific emphasis on wax-based anti-seawater corrosion treatment.

---

2. Equipment Profile: Towable Excavator (Typical Export Unit)

Parameter	Specification
Operating Weight	3,200 – 5,500 kg
Dimensions (L×W×H)	5.8 m × 2.0 m × 2.7 m (avg.)
Undercarriage Type	Rubber-tracked or steel-tracked
Drive System	Hydraulic, self-propelled
Towing Compatibility	ISO 500 mm drawbar, 50 mm ball coupling
Special Handling Requirements	Low-clearance loading, hydraulic lock-down

Note: Units are typically shipped in “assembled, ready-to-deploy” configuration unless disassembly is contractually required.

---

3. Comparative Shipping Methodology

Criteria	RO-RO (Roll-on/Roll-off)	Bulk Cargo (Loose Stowage)	Flat Rack Container (20′ or 40′)
Loading Method	Self-driven or towed onto vessel	Lifted via crane, stowed in hold	Lifted and secured on open-frame container
Stowage Location	Vehicle decks (enclosed or open)	Cargo holds (unprotected)	Deck or below-deck in container stack
Cargo Protection	Moderate (exposed to deck conditions)	Low (high moisture, shifting risk)	High (weatherproof lashings, tarp optional)
Turnaround Time (Port)	Fast (2–4 hrs)	Medium (6–12 hrs)	Medium (4–8 hrs)
Risk of Damage	Low (drivable units)	High (crane handling, chafing)	Low–Moderate (if properly secured)
Insurance Premium	Moderate	High	Moderate
Cost (USD/unit, avg.)	$950 – $1,300	$700 – $1,000	$1,400 – $1,900
Best Suited For	Intact units, frequent shipments	High-volume, low-value fleets	High-value units, harsh climate routes
Corrosion Exposure Risk	High (direct salt spray on deck)	Very High (condensation in holds)	Moderate (controlled lashings, tarp cover)

Costs based on Shanghai to Rotterdam route, Q2 2026 freight indices.

---

4. Corrosion Protection Protocol: Wax Spraying System

To mitigate seawater-induced corrosion during transit—particularly critical in RO-RO and Bulk Cargo modes—SEA LION International mandates application of industrial-grade anti-corrosion wax emulsion prior to shipment.

4.1 Wax Spraying Specifications

Parameter	Requirement
Wax Type	Solvent-free, hydrophobic microcrystalline wax
Application Method	High-pressure spray (15–20 bar)
Coverage Areas	Undercarriage, hydraulic cylinders, track links, exposed steel joints, fuel/hydraulic line fittings
Film Thickness	25–40 µm (measured via wet-film gauge)
Drying Time	4–6 hours (ambient 25°C)
Salt Spray Resistance (ASTM B117)	>500 hours (no red rust)
Removal Post-Delivery	Biodegradable citrus-based solvent or steam wash

4.2 Protection Efficacy by Shipping Mode

Shipping Mode	Corrosion Risk (Unprotected)	Risk with Wax Treatment	Notes
RO-RO	High	Moderate	Wax reduces salt adhesion on undercarriage; reapplication recommended post-delivery
Bulk Cargo	Very High	High	Limited protection due to prolonged humidity exposure in holds
Flat Rack	Moderate	Low	Tarp coverage + wax provides optimal defense; ideal for tropical/transoceanic routes

Field data: Wax-treated units show 78% lower incidence of hydraulic seal degradation and track corrosion after 21-day Pacific crossing.

---

5. Recommendations by Use Case

Client Profile	Recommended Method	Rationale
High-volume fleet (10+ units)	RO-RO	Fast loading, lower handling risk, scalable logistics
Premium excavators (> $65k/unit)	Flat Rack + Wax + Tarp	Maximum protection, traceable stowage, reduced insurance claims
Budget-sensitive, inland delivery	Bulk Cargo (with wax)	Lowest freight cost; acceptable risk if post-inspection maintenance is budgeted

---

6. Compliance & Documentation

All shipments must comply with:
– IMSBC Code (for Bulk Cargo)
– CTU Code (Cargo Transport Unit – for Flat Rack)
– IMDG Class 9 (if lithium components present)
– China Customs Export Declaration (Form EX1)
– Bill of Lading (Sea Waybill or Telex Release)

Wax application must be certified per ISO 12944-2 (Corrosion Protection of Steel Structures) and documented in the Pre-Shipment Inspection (PSI) report.

---

7. Conclusion

For towable excavator exports from China, RO-RO offers the best balance of speed and cost for standard units, while Flat Rack with wax protection is superior for high-value or climate-sensitive deliveries. Bulk Cargo remains viable only under strict wax application and post-arrival refurbishment protocols.

Wax spraying is not optional—it is a critical engineering control to preserve equipment integrity across all shipping modes.

SEA LION International enforces wax treatment as standard on all excavator shipments and provides third-party validation reports upon request.

---

End of Report – SEA LION International Engineering Division – Rev. 3.1, 2026-Q2
