Overview: Used Small Excavator for Global Markets

INDUSTRIAL SPECIFICATION REPORT 2026: EXECUTIVE OVERVIEW

Subject: SEA LION International Certified Pre-Owned Small Excavator (6-8 Ton Class)
Target Audience: Fleet Managers, Construction & Mining Operations Directors

---

1. Core Application & Operational Value

The SEA LION Certified Pre-Owned (CPO) 6-8 Ton Small Excavator addresses critical operational demands in mining support, urban logistics, and infrastructure construction where space constraints, fuel efficiency, and rapid deployment are paramount. Field data from 2025 deployments confirms:

Application	Key Use Cases	SEA LION CPO Advantage (vs. New)
Mining	Trenching for utilities, loading light ore, site preparation	22% lower operating cost/ton; compact size enables work in confined pit areas
Logistics	Container yard management, warehouse site prep, material handling	35% faster mobilization; 18% reduced fuel consumption in stop-start cycles
Construction	Residential/utility trenching, landscaping, foundation work	94% uptime (vs. industry avg. 85%); precise grading capability (±5mm accuracy)

Source: SEA LION 2025 Field Performance Database (1,200+ units deployed)

---

2. Regional Market Preference: Africa, Russia, Southeast Asia

This model dominates in target regions due to operational resilience, cost structure alignment, and SEA LION’s localized support infrastructure – directly addressing regional pain points:

Region	Critical Requirements Met by SEA LION CPO Excavator	Competitive Edge vs. Alternatives
Africa	Dust tolerance (ISO 4413 Class 3 filtration); high-ambient temp operation (55°C+); low-cost maintenance	40% lower parts cost via SEA LION’s XCMG-certified hubs; 72-hr spare parts guarantee
Russia	Extreme cold starts (-40°C); reinforced undercarriage for permafrost; fuel flexibility (Arctic diesel)	Proven -45°C startup reliability (SINOTRUK engine heritage); 30% fewer hydraulic leaks in sub-zero ops
Southeast Asia	High humidity corrosion resistance; compact transport (fits 20ft container); monsoon-ready sealing	SEA LION’s marine-grade refurbishment adds 2-3 years service life; 28% lower TCO over 5 years

Key Driver: SEA LION’s 18-year heavy equipment export framework ensures parts/logistics parity with new equipment in remote regions.

---

3. SEA LION Value Proposition: Beyond “Used”

SEA LION transforms used equipment risk into predictable operational asset performance through industrial-grade processes:

Refurbishment Phase	Specification	Verification Standard
Core Assessment	Full hydraulic circuit pressure test; structural weld inspection (UT/MT)	ISO 9001:2015; 1,500-hr max operational threshold
Component Renewal	Seals/bearings replaced; undercarriage rebuilt to OEM spec; electrical system overhaul	XCMG/SINOTRUK original parts only
Validation	50-hr burn-in test; load simulation; GPS-tracked field trial	98.5% pass rate (2025 data)

Fleet Manager Benefits:
– TCO Reduction: 32-41% lower total cost of ownership vs. new (5-year horizon)
– Uptime Assurance: 18-month/3,000-hr comprehensive warranty; 24/7 remote diagnostics via SEA LION FleetLink™
– Supply Chain Integration: Seamless parts compatibility with SEA LION’s SINOTRUK/SHACMAN truck fleets (shared logistics network)

---

4. Strategic Recommendation

For fleet managers operating in capital-constrained, high-utilization environments across Africa, Russia, and Southeast Asia, SEA LION’s CPO Small Excavator delivers new-equipment reliability at 60-65% of acquisition cost – without compromising on safety, productivity, or parts traceability. Our industrial refurbishment protocol and established regional service infrastructure eliminate the traditional risks of the used equipment market, enabling immediate ROI on infrastructure and resource projects.

SEA LION International: Engineering Asset Longevity Since 2006.

---

Report Validity: January 2026 – December 2026 | Data Source: SEA LION Global Equipment Performance Registry

Technical Specifications & Parameters

Industrial Specification Report 2026

Target Audience: Fleet Managers & Construction Companies
Subject: Technical Evaluation of Used Small Excavator (Standard Configuration)

---

Technical Specifications: Used Small Excavator (20–25 Ton Class)

The following specifications represent a typical high-utilization, pre-owned small hydraulic excavator commonly encountered in secondary markets across industrial and infrastructure sectors. Units are assumed to be from 2020–2023 production with moderate wear and standard OEM configurations. Engine, transmission, and axle systems reflect common Chinese OEM integrations found in value-engineered models widely deployed in roadwork, urban utility, and foundation projects.

Parameter	Specification
Engine Model	Weichai WD615 Series (Tier II/III Compliant)
Rated Horsepower	184 hp (137 kW) @ 2,200 rpm
Transmission Type	HW19710 Dual-Range Mechanical Transmission
Drive Configuration	4×4 Full-Time Mechanical 4WD with Locking Differentials
Front Axle Load	8,200 kg (18,078 lbs)
Rear Axle Load	9,800 kg (21,605 lbs)
Tire Specifications	12.00R20, Radial, Load Range G, 16PR, Off-Road Tread
Operating Weight	22,000 kg (48,500 lbs) – typical configuration
Bucket Capacity	1.0 – 1.3 m³ (standard general-purpose bucket)

---

Fuel Efficiency Analysis

Fuel consumption is measured under ISO 9249-compliant test conditions simulating mixed operation (40% digging, 30% swinging, 30% travel).

• Average Fuel Consumption: 28–32 L/h during peak load operations
• Cruising Efficiency (Travel Only): 18–22 L/h at 25 km/h on graded haul roads
• Fuel Tank Capacity: 350 L
• Estimated Operational Range: 10–12 hours at 65% load factor

The Weichai WD615 engine, while not meeting latest Tier IV Final emissions standards, maintains robust fuel delivery calibration and high torque retention at low RPMs (peak torque: 880 N·m @ 1,400 rpm), contributing to stable efficiency in stop-start excavation cycles. Fleet telemetry data from 2024–2025 deployments indicates a 12–15% increase in fuel use compared to newer electronically controlled engines, but with significantly lower maintenance overhead.

Note: Units retrofitted with fuel optimization kits (e.g., calibrated injectors, turbo upgrades) have demonstrated up to 8% improvement in fuel economy under consistent load profiles.

---

Load Capacity & Structural Performance

• Maximum Digging Depth: 6,800 mm
• Maximum Reach at Ground Level: 9,900 mm
• Swing Torque: 42 kN·m
• Tractive Effort: 165 kN

The HW19710 transmission provides 4 forward and 4 reverse gears with two-speed range selection, enabling precise control in high-resistance digging and efficient travel across unpaved terrain. Axle load distribution (42% front / 58% rear) ensures stability during lifting operations within SAE J1097-rated zones.

• Lift Capacity (Over Front, 6m radius): 3,100 kg
• Tipping Load (Static, Full Boom Extension): 6,200 kg

Tires (12.00R20) are rated for 3,600 kg per tire at 5 bar inflation, suitable for soft to medium-compacted surfaces. Field reports indicate acceptable wear life of 1,800–2,400 operating hours depending on terrain abrasiveness and load adherence.

---

Summary for Fleet Deployment

Used small excavators equipped with the Weichai WD615/HW19710 drivetrain offer a cost-effective solution for mid-intensity construction cycles where availability and mechanical simplicity outweigh emissions compliance requirements. With proper maintenance, these units sustain 6,000–8,000 total operating hours before major overhaul. Their predictable load behavior and high axle capacity make them suitable for integration into mixed-age fleets operating in rural infrastructure, pipeline, and municipal projects.

Recommendation: Conduct pre-acquisition inspection focusing on transmission bearing play, axle seal integrity, and tire casing fatigue—common wear points after 4,000+ hours.

Quality Control & Inspection Standards

SEA LION INTERNATIONAL

INDUSTRIAL SPECIFICATION REPORT: REFURBISHED SMALL EXCAVATOR PROCESS
EFFECTIVE DATE: JANUARY 1, 2026
REPORT ID: SL-RFX-SME-2026-01

---

1. EXECUTIVE SUMMARY

SEA LION International delivers rigorously refurbished small excavators (1.5–6.0 ton class) meeting ISO 20474-1:2021 operational safety standards. This report details the mandatory 4-phase refurbishment protocol, emphasizing zero-tolerance inspection criteria to ensure 95%+ operational readiness for demanding construction and fleet deployment. All units undergo 127-point validation before release.

---

2. REFURBISHMENT PROCESS & SEA LION INSPECTION STANDARDS

Each unit progresses sequentially through the following phases. Non-conformance at any stage mandates component rejection or process repetition.

PHASE 1: ENGINE & GEARBOX TESTING

Comprehensive validation per SAE J1925 & ISO 1585 standards.

Test Parameter	SEA LION MIN. ACCEPTANCE	Testing Method	Failure Threshold
Engine Compression	≥95% of OEM spec (all cyl.)	Hydraulic pressure transducer	>8% deviation between cylinders
Oil Analysis (Spectro)	<15 ppm ferrous wear	Lab-certified spectrometry	>25 ppm ferrous wear
Gearbox Torque Output	≥98% rated capacity	Dynamometer load test (3 cycles)	>5% power loss
Thermal Stability	ΔT ≤ 15°C @ full load (60 min)	Infrared thermal imaging	ΔT > 25°C

All engines undergo 2-hour burn-in test. Gearboxes inspected for pitting, scoring, and bearing play using dial indicators (max. 0.05mm axial play allowed).

PHASE 2: CABIN REPAINTING

Corrosion prevention and operator safety focus. ASTM D3359 adhesion standard enforced.

• Surface Prep:
• Abrasive blasting to Sa 2.5 standard (ISO 8501-1)
• Epoxy primer application (75μm DFT) with zinc phosphate conversion coating
• Paint Application:
• 2-component polyurethane topcoat (RAL 5005/7035)
• 120μm dry film thickness (DFT) minimum, verified via Elcometer 456
• Quality Gate:
• Zero pinholes/craters in final coat
• Cross-hatch adhesion test: 5B rating (ASTM D3359)
• UV resistance: Pass 500-hr QUV accelerated weathering (ASTM G154)

PHASE 3: NEW TIRES & BATTERY REPLACEMENT

OEM-spec components only. No rebuilt or retreaded parts permitted.

Component	SEA LION SPECIFICATION	Verification Protocol
Tires	OEM-recommended model (e.g., CEAT Earth Mover)	Load index ≥ 110, Speed rating B
	New, unused stock (max. 6-month shelf life)	Date-stamped receipt validation
Battery	12V AGM (Absorbent Glass Mat)	Cold Cranking Amps (CCA) ≥ 650
	SEA LION-certified supplier only	Voltage stability test @ -18°C

All tires balanced to ISO 13327:2012. Batteries subjected to 3-cycle charge/discharge validation.

PHASE 4: CHASSIS REINFORCEMENT

Structural integrity restoration per ASME B30.5-2021 mobile crane standards.

• Inspection Protocol:
• Ultrasonic thickness testing (UT) at 12 critical stress points (min. 8mm remaining wall thickness)
• Magnetic particle inspection (MPI) of boom/pin interfaces (ASTM E709)
• Reinforcement Actions:
• Cracked weld zones: Full cut-out + TIG re-weld with ER70S-6 filler (110% OEM thickness)
• Frame flex points: 6mm high-tensile steel gusset plates (ASTM A572 Gr. 50)
• Post-weld stress relief: Thermal cycling to 600°C ± 25°C
• Final Validation:
• Load test: 150% rated capacity @ full extension (3 cycles)
• Deflection tolerance: ≤ 2mm at boom tip (laser alignment verification)

---

3. SEA LION QUALITY ASSURANCE MANDATES

• Traceability: Each component tagged with QR-linked refurbishment log (ISO 9001:2015 compliant).
• Rejection Rate: 22% of incoming units fail Phase 1 testing (2025 fleet data). Non-repairable units scrapped.
• Final Certification:
• 100-hour operational test (simulated digging, lifting, travel)
• Emissions compliance: Tier 4 Final equivalent (ISO 8178-4)
• Full hydraulic system pressure test: 150% max working pressure (no leaks)

---

4. CONCLUSION

SEA LION’s 2026 refurbishment protocol eliminates field failure risks inherent in non-certified used equipment. By enforcing stricter tolerances than OEM rebuild specifications (e.g., 98% vs. 95% torque retention), we deliver machines with 85% of new-unit lifecycle at 40% of acquisition cost. All refurbished excavators include 12-month structural warranty and 500-hour powertrain coverage.

SEA LION International: Engineered Reliability for Industrial Operations

---

END OF REPORT
Revision 2.1 | Controlled Document

Shipping & Logistics Solutions

Industrial Specification Report 2026

Prepared by: SEA LION International – Senior Engineering Division
Subject: Logistics Solutions for Exporting Used Small Excavators from China
Target Audience: Fleet Managers & Construction Companies

---

Executive Summary

This report evaluates three primary maritime transport methods—Roll-on/Roll-off (RO-RO), Bulk Cargo, and Flat Rack container shipping—for the export of used small excavators (operating weight: 2–6 metric tons) from major Chinese ports (e.g., Shanghai, Qingdao, Ningbo) to global destinations. The analysis includes cost-efficiency, equipment integrity, transit time, handling requirements, and corrosion protection protocols, with emphasis on wax-based anti-corrosion treatments for seawater exposure.

---

1. Equipment Profile: Used Small Excavators

Parameter	Specification
Model Range	CAT 301.8–305.5, Komatsu PC30–60, Hitachi ZX35–60
Operating Weight	2.0 – 6.0 metric tons
Dimensions (L×W×H)	3.2 – 5.8 m × 1.6 – 2.0 m × 2.4 – 2.9 m
Fuel Status (Pre-shipment)	Drained (fuel tank & hydraulic system)
Mobility	Self-propelled; track-driven
Condition	Used, post-decommissioning inspection

---

2. Comparative Shipping Methods

Criteria	RO-RO (Roll-on/Roll-off)	Bulk Cargo (Loose Stowage)	Flat Rack Container (20′ or 40′)
Loading Mechanism	Self-driven onto vessel	Crane-lifted into hold	Crane-lifted onto open-frame container
Stowage Density	High (efficient stacking)	Moderate (variable securing)	Low to Moderate (limited per vessel)
Securing Method	Wheel chocks, lashing straps	Wooden cradles, steel lashing	Twist locks, lashing bars, dunnage
Port Infrastructure	Requires RO-RO ramp	General cargo berth	Container terminal with reach stacker
Transit Time (China → EU)	28–35 days	30–40 days	32–42 days
Average Cost per Unit (USD)	$1,100 – $1,400	$900 – $1,200	$1,600 – $2,200
Risk of Damage	Low (minimal handling)	High (crane impact, shifting)	Moderate (exposure to elements)
Weather Exposure	Partial (decks may be open)	Low (below deck)	High (fully exposed)
Customs Clearance	Standard documentation	Requires detailed cargo manifest	ISPM 15 & containerized cargo norms
Best Suited For	High-volume, time-sensitive shipments	Low-cost, non-urgent consignments	Oversized or non-self-propelled units

Note: All costs are FOB China, based on Q1 2026 freight indices and average fuel surcharges.

---

3. Corrosion Protection: Wax Spraying System

Marine environments expose metal surfaces to salt-laden air and condensation, accelerating corrosion during transit (average humidity: 75–95% RH). To mitigate degradation of hydraulic cylinders, undercarriage, and pivot joints, SEA LION International mandates a wax-based anti-corrosion treatment prior to shipment.

3.1. Wax Spraying Protocol

Step	Procedure	Specification
1	Surface Preparation	Degrease, dry, remove loose debris
2	Application Method	High-pressure electrostatic spray
3	Coating Type	Solvent-free, hydrophobic microcrystalline wax
4	Layer Thickness	25–35 µm (uniform coverage)
5	Curing Time	4–6 hours at 20°C
6	Protected Zones	Tracks, boom pins, hydraulic rods, radiator fins

3.2. Performance Metrics

Property	Value
Salt Spray Resistance (ASTM B117)	>500 hours (no red rust)
Water Displacement	>98%
Temperature Stability	-20°C to +60°C
Removability	Biodegradable citrus-based solvent

Compliance: Meets ISO 12944-2:2019 (Corrosion Protection of Steel Structures) and JIS Z 0302 (Marine Transport Preservation).

---

4. Risk Mitigation & Recommendations

Risk Factor	RO-RO	Bulk Cargo	Flat Rack
Corrosion	Moderate	Low	High (exposure)
Structural Damage	Low	High	Moderate
Theft/Vandalism	Low (secured decks)	Moderate (hold access)	High (exposed units)
Delays (Port Congestion)	Low	Moderate	High (container queues)

Recommended Use Cases:

• RO-RO: Optimal for fleet managers exporting 10+ units with operational mobility. Offers fastest turnaround and lowest handling risk.
• Bulk Cargo: Suitable for budget-driven projects where equipment will undergo full refurbishment post-import.
• Flat Rack: Recommended only for excavators with attachments (e.g., breakers, augers) or non-functional undercarriages.

---

5. Conclusion

For the export of used small excavators from China, RO-RO shipping provides the best balance of cost, speed, and equipment protection, particularly when combined with industrial-grade wax spraying. While Bulk Cargo offers lower base rates, increased damage risk offsets savings. Flat Rack should be reserved for exceptional dimensional cases.

SEA LION International advises all clients to implement mandatory pre-shipment wax encapsulation and GPS-enabled telematics tagging for real-time monitoring of environmental exposure during transit.

---

End of Report
SEA LION International – Engineering Division | Rev. 2026.04
