Spare Parts for chinese electric tour bus
Now we have 20 units Toyota Coaster and Coach bus ready for shipment, which were produced in 2006-2014, price is very good.
|
Bus name / Bus length
|
12m Pure electric city bus
|
10m Pure electric city bus
|
8m Pure electric city bus
|
6m Pure electric city bus
|
|
Length×Width×Height(mm)
|
12000×2550×3090，3210 (air-conditioner)
|
10450×2500×3220
|
8050x2500x3120, 3250
|
6645x2355x2915, 3130
|
|
Bus body
|
Fully integral, Monocoque body
|
Fully integral, Monocoque body
|
Semi-monologue body, two steps
|
Semi-monologue body, three steps, leveling board
|
|
Rated passenger capacity (person)
|
88/20～50
|
68/20～40
|
50/15~35
|
40 /15~30
|
|
Total weight (kg)
|
18000
|
16000
|
14000
|
12000
|
|
Curb weight (kg)
|
13500 (air-conditioner)
|
12600 (air-conditioner)
|
10900 (air-conditioner)
|
9800 (air-conditioner)
|
|
Consumption, under specified working conditions (kmh/100km)
|
80kwh
|
68kwh
|
50kwh
|
45kwh
|
|
Max. speed(km/h)
|
69
|
69
|
69
|
69
|
|
Max Driving range ,(km)
|
280
|
240
|
220
|
200
|
|
Battery
|
585.6V /183AH(281.1kw.h)
|
LiFePO4, 191.5kwh, 537.6 DC
|
110.6KW.H battery with heating system
|
384V/160AH, 61.4Kw.h
|
|
Suspension system
|
Less leaf spring, 3/ 4. Optional Air suspension
|
Less leaf spring, 3/ 4.
Optional Air suspension |
Less leaf spring, 3/ 4. Optional Air suspension
|
Less leaf spring, 3/ 4
|
|
steering gear system
|
Imported hydraulic power assisted steering gear
|
Imported hydraulic power assisted steering gear
|
Imported hydraulic power assisted steering gear
|
Imported hydraulic power assisted steering gear
|
|
Brake
|
Dual-circuit pneumatic braking system;front disc brake
|
Dual-circuit pneumatic braking system;front disc b
|
Dual-circuit pneumatic braking system;front disc b
|
Dual-circuit pneumatic braking system;front disc b
|
|
Tyre model
|
275/70R22.5
|
275/70R22.5
|
255/70R22.5
|
215/75R17.5
|
